Saia PCD2 programmable controllers
Overview of Saia PCD2 device series
Saia PCD2.M5 controllers
Page
42
Base units with 8 slots for I/O modules
PCD2.M5440 Basic
PCD2.M5540 Extended with Ethernet switch
Up to 4 integrated communication interfaces, can be expanded to
max. 15 communication interfaces with plug-in modules. Integrated
Automation Server in all CPUs.
Saia PCD2 module holder for I/O expansion
Page
43
Module holder for I/O modules
PCD2.C1000 4 I/O slots
PCD2.C2000 8 I/O slots
Expansion to max. 1,023 I/Os
Saia PCD2 input/output modules
Page
45
Modules with various functions with plug-in terminals
PCD2.Exxx Digital input modules
PCD2.Axxx Digital output modules
PCD2.Bxxx Combined digital input/output modules
PCD2.Wxxx Analog input/output modules
Saia PCD2 interface modules
Page
48
Plug-in modules to expand the communication interfaces
(up to 4 modules or 8 interfaces)
PCD7.F1xxS 1 serial interface RS-232, RS-422/485, Belimo MP-Bus
PCD2.F2xxx 2 serial interfaces RS-232, RS-422/RS-485
PCD2.F2150 BACnet® MSTP
PCD2.F2610 DALI
PCD2.F27x0 M-Bus
PCD2.F2180 Belimo MP-Bus
Saia PCD2 memory modules
Page
49
Plug-in memory modules for data and program backup
PCD2.R6xx
Basic module for SD flash memory card for slots 0…3
PCD7.R-SD
SD flash memory cards for PCD3.R6xx
PCD7.R5xx Flash memory module for slots M1 & M2
Consumables and accessories for Saia PCD2 controllers
Page
52
Housing covers, plug-in screw terminal blocks,
I/O bus connection, battery, system cables and adapters
