Accessories and consumables for the Saia PCD2.M5xxx controllers
Fast labeling of I/O modules with Saia LabelEditor
The software tool is used to efficiently label the PCD2 labeling strip. The unique
data point text can be entered in the tool by the user In the tool, the unique data
point text to be entered by the user. These can then be printed on A4 paper. For
the different types of PCD2 modules, the user selects appropriate distance for-
mats. The entered text can be saved as templates and reused.
SBC Label Editor is supplied with Saia PG5 Controls Suite.
Download area:
www.sbc-support.com
EPLAN macros
For project planning and engineering
EPLAN macros are available
ePLAN® electric P8 macros are available from the
support page.
Macros and product data may also be obtained
from the ePLAN® data portal.
