Saia PCD2 Analog input and output modules
The numerous analog modules allow complex control tasks or measurements. Depending on the speed of the AD converter, the resolu-
tion is between 8 and 16-bit. The digitized values can be processed further directly in the project in PCD2 and PCD1. The large number
of different modules means that suitable modules can be found to cover nearly every requirement.
Analog input modules
Type/
Order no.
Total
channels Signal range
Resolution
Electrical
isolation
Current draw
5 V bus
1)
+ V bus
2)
I/O connector
type
3)
PCD2.W200
PCD2.W210
PCD2.W220
PCD2.W220Z02
PCD2.W220Z12
8 I
8 I
8 I
8 I
4 I +
4 I
0…+10 V
0…20 mA (4…20 mA via user program)
Pt1000: –50°C…400°C/Ni1000: –50°C…+200°C
NTC10 temperature sensor
4 I: 0…10 V and
4 I: Pt1000: –50°C…400°C/Ni1000: –50°C…+200°C
10-bit
10-bit
10-bit
10-bit
10-bit
---
8 mA
8 mA
8 mA
8 mA
8 mA
5 mA
5 mA
16 mA
16 mA
11 mA
L
L
L
L
L
PCD2.W300
PCD2.W310
PCD2.W340
PCD2.W350
PCD2.W360
PCD2.W380
8 I
8 I
8 I
8 I
8 I
8 I
0…+10 V
0…20 mA (4…20 mA via user program)
0…+10 V/0…20 mA (4…20 mA via user program)
Pt1000: –50°C…400°C/Ni1000: –50°C…+200°C
Pt100: –50°C…+600°C/Ni100: –50°C…+250°C
Pt1000: –50°C…+150°C
–10 V…+10 V, –20 mA…+20 mA, Pt/Ni1000, Ni1000 L&S,
NTC10k/NTC20k (configuration via user program)
12-bit
12-bit
12-bit
12-bit
12-bit
13-bit
---
8 mA
8 mA
8 mA
8 mA
8 mA
25 mA
5 mA
5 mA
20 mA
30 mA
20 mA
25 mA
L
L
L
L
L
2× K
PCD2.W305
PCD2.W315
PCD2.W325
7 I
7 I
7 I
0…+10 V
0…20 mA (4…20 mA via user program)
–10 V…+10 V
12-bit
12-bit
12-bit
●
●
●
60 mA
60 mA
60 mA
0 mA
0 mA
0 mA
P
P
P
PCD2.W720
2 I
Weighing module with 2 systems for up to 6 weighing cells
≤ 18 bit
---
60 mA 100 mA
P
PCD2.W745
4 I
Temperature module for TC type J, K and 4-wire Pt/Ni 100/1000
16 bit
●
200 mA 0 mA
R
Analog output modules
Type/
Order no.
Total
channels Signal range
Resolution
Electrical
isolation
Current draw
5 V bus
1)
+ V bus
2)
I/O connector
type
3)
PCD2.W400
PCD2.W410
4 O
4 O
0…+10 V
0…+10 V/0…20 mA/4…20 mA jumper-selectable
8-bit
8-bit
---
1 mA
1 mA
30 mA
30 mA
L
L
PCD2.W600
PCD2.W610
4 O
4 O
0…+10 V
0…+10 V/–10 V…+10 V/0…20 mA/4…20 mA jumper-selectable
12-bit
12-bit
---
4 mA
110 mA
20 mA
0 mA
L
L
PCD2.W605
PCD2.W615
PCD2.W625
6 O
4 O
6 O
0…+10 V
0…20 mA/4…20 mA, parameters can be set
–10 V…+10 V
10-bit
10-bit
10-bit
●
●
●
110 mA
55 mA
110 mA
0 mA
0 mA
0 mA
P
P
P
Analog input/output modules
Type/
Order no.
Total
channels Signal range
Resolution
Electrical
isolation
Current draw
5 V bus
1)
+ V bus
2)
I/O connector
type
3)
PCD2.W525
4 I +
2 O
I:0…10 V, 0(4)…20 mA, Pt1000, Pt500 or Ni1000
(selectable by DIP switch)
O:0…10 V or 0(4)…20 mA (selectable by software)
I: 14-bit
O: 12-bit
●
40 mA 0 mA
P
Saia PCD2 mixed digital and analoge input and output modules
With the multi-function I/O module PCD2.G200 a total of 24 digital and analog inputs and
outputs is achieved. Thus, the need for additional module holders can be avoided, and
sophisticated small applications can be implemented cost-effectively.
Multifunction input/output modules
Type/
Order no.
Total
channels Signal range
Resolution
Input
filter
Electrical
isolation
Current draw
5 V bus
1)
+ V bus
2)
I/O connector
type
3)
PCD2.G200
4 I
Digital: 15…30 VDC
8 ms
---
12 mA 35 mA KB black
4 O Digital: 0.5 A/10…32 VDC
---
KB black
2 I
2 I
4 I
Analog: 0…10 V
Analog: Pt1000 or Ni1000
Analog: universal, 0…10 V, 0…20 mA,
Ni/Pt1000 (selectable by DIP switch)
12 bit
12 bit
12 bit
10 ms
20 ms
10 ms
Ni/Pt 20 ms
---
K orange
8 O Analog: 0…10 V
10 Bits
---
K orange
1)
2)
3)
See page 46
