Plug-in screw terminal blocks
4 405 5089 0 Plug-in screw terminal block, 11-pole, labeling 0…10
Terminal X0
4 405 5087 0 Plug-in screw terminal block, 9-pole, labeling 11…19
Terminal X1
4 405 5088 0 Plug-in screw terminal block, 10-pole, labeling 20…29
Terminal X2
4 405 4919 0 Plug-in screw terminal block, 10-pole, labeling 30…39
Terminal X3
Cover
4 104 7759 0 Housing cover for PCD1.M2xxx without logo
can be individually designed on site with a foil
Battery for data backup
Type
Description
4 507 4817 0 Lithium battery for PCD processor unit (RENATA button battery type CR 2032)
Accessories and consumables for Saia PCD1.M2xxx
For small and medium installations
Modernization and enhancement of existing installations through the compact design, for example
Various interface options, including to existing installations as a gateway.
For example, optimization of a cooling system by setting all the free parameters
Labeling
The self-adhesive labels can be printed directly with the
SBC LabelEditor from the PG5 Device Configurator
Use as communication interface
with M-Bus in a district heating
network
Range of uses
Connection to an existing EIB/KNX installation
providing conference rooms with a web connection
ePLAN® electric P8 macros are available from the
support page.
Macros and product data may also be obtained
from the ePLAN® data portal.
