Automation stations – Saia PCD1
5
4
3
2
1
Cabinet
components
Dedicated
room controller
HMI Visualization
and operating
Automation
stations
Consumption data
acquisition
On-Board inputs/outputs
Inputs
6 Digital inputs (4 + 2 interrupts)
15…30 VDC, 8 ms / 0,2 ms input filter
Terminal X1
2 Analog inputs, selectable via DIP switch,
preconfigured for Ni1000 in the default setup
–10…+10 VDC, 0…+/–20 mA,
Pt1000, Ni1000, Ni1000 L&S, 0…2.5 kΩ
Terminal X1
Outputs
4 Digital outputs
24 VDC
Terminal X0
1 PWM output
24 VDC / 0.2 A
Terminal X0
selectable/configurable via PG5
4 Digital inputs or outputs,
preconfigured for digital inputs in the default setup
24 VDC / data as digital inputs resp. outputs
Terminal X0
1 Watchdog relay or as make contact
48 VAC or VDC, 1 A
mount a free wheeling diode over the load when switching DC-tension
Terminal X3
General data
Supply voltage
24 VDC, –20/+25% max. incl. 5% ripple (in accordance with EN/IEC61131-2)
Battery for data backup (exchangeable)
Lithium battery with a service life of 1 to 3 years
Operating temperature
0…55 °C
Dimensions (W×H×D)
142 × 142 × 60 mm
Type of Mounting
Top-hat rail according to DIN EN60715 TH35 (1 × 35 mm) or on a flat surface
Protection type
IP 20
Capacity 5V/+V(24V) internal
max. 500 mA/200 mA
Power consumption
typically 12 W
Automation Server
Flash memory, Filesystem, FTP andWeb-Server, E-Mail, SNMP
Installation instructions and recommendations
Mounting in electrical cabinet
The Saia PCD1.M0160E0 is sized 142
×
142
×
60 mm, excluding terminals and connectors.
For proper installation, a space of 55 mm should be left above the DIN rail and 75 mm below it.
Ethernet cable
For installation in the sub electrical cabinet unit, angled or flexible network cable (e.g. SlimWire PRO) is recommended.
If conventional network cable is installed, mounting of the sub electrical cabinet cover cannot be guaranteed.
Technical data
PCD1.M0160E0
Memory and file system
Program memory, DB/text (Flash)
1 MByte
Working memory, DB/text (RAM)
1 MByte
User flash file system onboard
128 MByte
Integral communication
Ethernet connection (2 port switch)
10/100 Mbit/s, full duplex, autosensing, auto-crossing
yes
USB connection
USB 1.1 device 12 Mbit/s
yes
RS-485 (terminal X3)
up to 115 kbit/
s
yes
Overview Saia PCD® E-Controller (PCD1.M0160E0)
Automation Server
integrated in
the base unit
Analogue output module Saia PCD7.W600 *)
This new analogue outputs (range 0 to +10 V) with 12 bits resolution has been especially developed for the new
PCD1 CPU (PCD1.M2xxx, PCD1.M0160E0, PCD1.M2110R1 ). It can be plugged in the slot A instead of a commu-
nication interface.
*
)
In preparation, see section C2 Product status
