PCS
1
PCS1.C8XX
J15
OPEN
RS 485
J16
J21
J19
J20
X4 (Port #1)
X1
X1 (Port #3)
X5
X6
J17
X7
J18
X9
J22
X8
4 5 6
3
87
10 9
1 2
43 1 2
4 5 6
3 1 2
3 1 2
4 5 6
3
87
1 2
4 5 6
3
87
101112
9
1 2
8 1012
6
16 14
2022
18
2 4
7 9 11
5
15 13
1921
17
1 3
8 1012
6
16 14
202224
18
2 4
7 9 11
5
15 13
192123
17
1 3
PCD7.FxxxS
+24VDC
GND
GND
Automation stations –
PCS1
Layout
RJ-11 for modem (Port 0)
Alternative PGU
programming interface
Three-color LED
can be
freely programmed
Graphic display with
single button operation
onboard data point
connection
RS-485 (X1 Port 3)
(S-Bus)
Programming interface PGU
(Port 0)
RS-232 (X3 Port 2)
Connection for slot A com-
munication modules
PCD7.F1xx(X4 Port 1)
Manual and
coupler level
L
ON
W
ORKS
® (X2)
Optional
terminal cover
PGU programming
interface
Slot for modem
module
Slot A for
communication module
PCS1.C42x
PCS1.C62x
PCS1.C82x
PCS1.C88x
Technical data
PCS1.C420
PCS1.C421
PCS1.C422
PCS1.C423
PCS1.C620
PCS1.C621
PCS1.C622
PCS1.C623
PCS1.C820
PCS1.C821
PCS1.C822
PCS1.C823
PCS1.C880
PCS1.C881
PCS1.C882
PCS1.C883
Internal graphic display
Ɣ Ɣ
–
–
Ɣ Ɣ
–
–
Ɣ Ɣ
–
–
Ɣ Ɣ
–
–
Manual operation
Ɣ
–
Ɣ
–
Ɣ
–
Ɣ
–
Ɣ
–
Ɣ
–
Ɣ
–
Ɣ
–
L
ON
FTT10
–
–
–
–
–
–
–
–
–
–
–
–
Ɣ Ɣ Ɣ Ɣ
Data points
Digital input 0.2 ms
0
2
3
3
Digital input 8 ms
4
4
9
9
Digital input/output
2
4
4
4
Relay output make contact
4
4
4
4
Relay output changeover contact
0
4
4
4
Universal input (0…10 V; 24 V on/off)
2
2
4
4
Analog input (Pt/Ni1000, 0.6° C)
0
0
4
4
Analog input (Pt/Ni1000, 0.15° C)
4
6
8
8
Analog output (0…10 V)
3
4
4
4
Total
19
30
44
44
Overview of PCS1
General data
Supply voltage
24 VDC -20/+25%, incl. 5% ripple in accordance with EN/IEC61131-2
Power consumption max. 10 W
Dimensions
195 × 150 × 60 mm (W × H × D)
User memory
1 MByte flash and 896 kByte RAM
Data storage
Flash > 10 years / RAM 5 days with super capacitor (user memory, hardware clock)
Processing time
Bit instruction 5 μs, word instruction 20 μs
Hardware clock
Time values: s/min/h, week/ day of the week, month/ day of the month, year deviation: < 60 s/month
PCS1 Media
Register (32 Bit)
R 0…4095
Timer / Zähler
T/C
0…1599
Flags (1 Bit)
F 0…8191
Text / Datenbausteine X/DB 0…5999
