Saia PCD® E-Controller (PCD1.M0160E0
)
Page
62
E-Controller for installation in electrical cabinet.
In the default setup, there are S-Monitoring (energy)
functionalities that can be adjusted with Saia PG5.
Type:
PCD1.M0160E0 with S-Monitoring function
18 integrated I/Os
no free I/O slots
The Saia PCD1 systems are the smallest programmable Saia PCD® controllers in a flat design. Alongside the standard communication
interfaces, integrated data memory and web/IT functionality, all controllers also have at least 18 integrated I/Os. The PCD1
controllers are ideally suited to small-scale automation tasks, whose challenges and issues can be successfully mastered by the
powerful CPU.
The many communication options are another advantage:
Ethernet TCP/IP, USB port, the onboard RS-485 interface and the expansion options with BACnet® or L
on
IP, for instance, are a small
example of the performance capability of PCD1.
1.4
Saia PCD1
1.4.2
Saia PCD1.Room (PCD1.M2110R1)
Page
58
Saia PCD1.Room
is for applications in the field
of room automation and HeaVAC.
Type:
PCD1.M2110R1 with Ethernet TCP/IP for
room automation applications
24 integrated I/O
1 free I/O slot
1.4.1
Saia PCD1.M2 series
Page
54
Saia PCD1.M2xxx
are compact
and may be modular extended.
Types:
PCD1.M2160 with Ethernet TCP/IP and expanded memory
PCD1.M2120 with Ethernet TCP/IP
PCD1.M2020 without Ethernet TCP/IP
18 integrated I/Os
2 free I/O slots
Possible use in
primary switch cabinet
Possible use in a room
(Example in a Room Box)
Possible use in a
electrical cabinet
