Capacity of the internal bus (5V, +V)
of the PCD3 controllers and module holders
Capacity
PCD3.Mxxx0
PCD3.Txxx
PCD3.C200
1)
Internal 5 V
600 mA
600 mA
1500 mA
2)
Internal +V (24 V)
100 mA
100 mA
200 mA
The electrical requirement of the internal +5V and +V bus for the I/O modules
is calculated in the PG5 Device Configurator.
Saia PCD3 Analogue input and output modules
The numerous analogue modules allow complex control tasks or measurements. Depending on the speed of the AD converter, the reso-
lution is between 8 and 16-bit. The digitized values can be processed further directly in the project in the Saia PCD3. The large number
of different modules means that suitable modules can be found to cover nearly every requirement.
Manual control modules
Analogue input modules
Type
Total
channels
Signal ranges/description
Resolution
Electrical
isolation
Internal current draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.W200
PCD3.W210
PCD3.W220
PCD3.W220Z03
PCD3.W220Z12
8 I
8 I
8 I
8 I
4 I
+4 I
0…+10 V
0…20 mA
4
)
Pt 1000: –50°C…400°C/Ni 1000: –50°C…+200°C
NTC10 temperature sensor
4 I: 0…10 V
4 I Pt 1000: –50°C…400°C/Ni 1000: –50°C…+200°C
10-bit
10-bit
10-bit
10-bit
10-bit
---
8 mA
8 mA
8 mA
8 mA
8 mA
5 mA
5 mA
16 mA
16 mA
11 mA
A
A
A
A
A
PCD3.W300
PCD3.W310
PCD3.W340
PCD3.W350
PCD3.W360
PCD3.W380
8 I
8 I
8 I
8 I
8 I
8 I
0…+10 V
0…20 mA
4
)
0…+10 V/0…20 mA
4
)
Pt 1000: –50°C…400°C/Ni 1000: –50°C…+200°C
Pt 100: –50°C…+600°C/Ni 100: –50°C…+250°C
Pt 1000: –50°C…+150°C
–10 V…+10 V, –20 mA…+20 mA, Pt/Ni1000, Ni1000 L&S,
NTC10k/NTC20k (configuration via user program)
12-bit
12-bit
12-bit
12-bit
12-bit
13-bit
---
8 mA
8 mA
8 mA
8 mA
8 mA
25 mA
5 mA
5 mA
20 mA
30 mA
20 mA
25 mA
A
A
A
A
A
2× K
PCD3.W305
PCD3.W315
PCD3.W325
7 I
7 I
7 I
0…+10 V
0…20 mA
4
)
–10 V…+10 V
12-bit
12-bit
12-bit
●
●
●
60 mA
60 mA
60 mA
0 mA
0 mA
0 mA
E
E
E
PCD3.W720
2 I
Weighing module with 2 systems for up to 6 weighing cells
≤18 Bit
---
60 mA 100 mA
E
PCD3.W745
4 I
Temperature module for TC type J, K
and 4-wire Pt/Ni 100/1000
16-bit
●
200 mA 0 mA
6
)
Analogue output modules
Type
Total
channels
Signal ranges/description
Resolution
Electrical
isolation
Internal current draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.W400
PCD3.W410
4 O
4 O
0…+10 V
0…+10 V/0…20 mA/4…20 mA jumper-selectable
8-bit
8-bit
---
1 mA
1 mA
30 mA
30 mA
A
A
PCD3.W600
PCD3.W610
4 O
4 O
0…+10 V
0…+10 V/–10 V…+10 V/0…20 mA/4…20 mA jumper-
selectable
12-bit
12-bit
---
4 mA
110 mA
20 mA
0 mA
A
A
PCD3.W605
PCD3.W615
PCD3.W625
6 O
4 O
6 O
0…+10 V
0…20 mA/4…20 mA parameters can be set
–10 V…+10 V
10-bit
10-bit
10-bit
●
●
●
110 mA
55 mA
110 mA
0 mA
0 mA
0 mA
E
E
E
PCD3.W800
4 O, 3 of which are
manually operated
0…+10 V, short circuit proofed
10-bit
---
45 mA 35 mA
5
)
J
Analogue input/output modules
Type
Total
channels
Signal ranges/description
Resolution
Electrical
isolation
Internal current draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.W525
4 I
+
2 O
I:
0…10 V, 0(4)…20 mA, Pt1000, Pt500 or Ni1000 (se-
lectable by DIP switch)
O: 0…10 V or 0(4)…20 mA (selectable by software)
I: 14-bit
O: 12-bit
●
40 mA 0 mA
E
PCD3.A810
Relay outputs, 2
changeover and 2 make
contacts
PCD3.A860
Light and shade 2 relay
outputs and 2 inputs
PCD3.W800
4 analog outputs
(3 channels with manual
control)
