Capacity of the internal bus (5V, +V)
of the PCD3 controllers and module holders
Capacity
PCD3.Mxxx0
PCD3.Txxx
PCD3.C200
1)
Internal 5 V
600 mA
600 mA
1500 mA
2)
Internal +V (24 V)
100 mA
100 mA
200 mA
The electrical requirement of the internal +5V and +V bus for the I/O modules
is calculated in the PG5 2.0 Device Configurator.
Saia PCD3 Digital input and output modules
The digital I/O modules can be easily plugged into the Saia PCD3 Basis CPU or an appropriate module holder. In addition to inputs for
various voltage levels, digital outputs are provided with both the transistor technology and as mechanical relays. This means that elec-
trical isolation from the switching electrical circuit can be achieved easily and reliably.
Digital input modules
Type
Number of I/Os
Input
voltage
Output breaking capacity
DC AC
Input
delay
Electrical
isolation
Internal current
draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.E110
PCD3.E111
PCD3.E112
PCD3.E116
8 I
8 I
8 I
8 I
15…30 VDC
15…30 VDC
7.5…15 VDC
3.5…7 VDC
---
---
8 ms
0.2 ms
9 ms
0.2 ms
---
24 mA
24 mA
24 mA
24 mA
---
A
A
A
A
PCD3.E160
PCD3.E161
16 I
16 I
15…30 VDC
15…30 VDC
---
---
8 ms
0.2 ms
---
10 mA
10 mA ---
D
D
PCD3.E165
PCD3.E166
16 I
16 I
15…30 VDC
15…30 VDC
---
---
8 ms
0.2 ms
---
10 mA
10 mA ---
C
C
PCD3.E500
6 I
80…250 VAC
---
---
20 ms
●
1 mA ---
A
PCD3.E610
PCD3.E613
8 I
8 I
15…30 VDC
30…60 VDC
---
---
10 ms
9 ms
●
●
24 mA
24 mA ---
A
A
Digital output modules
Type
Number of I/Os
Input
voltage
Output breaking capacity
DC AC
Input
delay
Electrical
isolation
Internal current
draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.A200
PCD3.A210
4 O, relay (make)
4 O, relay (break)
---
2 A/50 VDC
2 A/50 VDC
2 A/250 VAC
2 A/250 VAC
---
●
●
15 mA
15 mA ---
A
A
PCD3.A220
6 O, relay(make)
---
2 A/50 VDC 2 A/250 VAC
---
●
20 mA ---
A
PCD3.A251
8 O, relay
(6 changeover + 2 make)
---
2 A/50 VDC
2 A/48 VAC
---
●
25 mA ---
C
PCD3.A300
6 O, transistor
---
2 A/10…32 VDC
---
---
---
20 mA ---
A
PCD3.A400
8 O, transistor
---
0.5 A/5…32 VDC
---
---
---
25 mA ---
A
PCD3.A410
8 O, transistor
---
0.5 A/5…32 VDC
---
---
●
24 mA ---
A
PCD3.A460
PCD3.A465
16 O, transistor
16 O, transistor
---
0.5 A/10…32 VDC
0.5 A/10…32 VDC
---
---
---
10 mA
10 mA ---
D
C
PCD3.A810
Manual control
4 O, relay
(2 changeover + 2 make)
---
2 A/50 VDC
2 A/50 VDC
5 A/250 VAC
6 A/250 VAC
---
●
●
40 mA ---
F
Digital input/output modules
Type
Number of I/Os
Input
voltage
Output breaking capacity
DC AC
Input
delay
Electrical
isolation
Internal current
draw
5 V bus
1)
+ V bus
2)
I/O
connector
type
3)
PCD3.A860
Light&shade
2 O, relay (make)
2 I
15…30 VDC
---
12 A/250 VAC 8 ms
●
18 mA ---
G
H
PCD3.B100
2 I + 2 O + 4 selectable I or O I:15…32 VDC 0.5 A/5…32 VDC
---
8 ms
---
25 mA ---
A
PCD3.B160
16 I/O (configurable)
I: 24 VDC 0.25 A/18…30 VDC
---
8 ms or
0.2 ms
---
120 mA ---
2× K
3)
Plug-in I/O terminal blocks are included with I/O modules.
Spare terminals, ribbon connectors with system cables and separate termi-
nals are ordered as accessories (see page 34 and page 78).
4)
Delivery on demand
Fast counter modules (only for I/O slots with fast SPI bus)
Type
Number of
counters
Inputs per counter
Outputs
per counter
Counting range
Selectable
digital filter
Current draw
5 V bus
1)
+ V bus
2)
I/O connector
type
3)
PCD3.H112
4)
2
2 I + 1 configurable I
1 CCO
0…16777215 (24-bit) 10 kHz…150 kHz 50 mA 4 mA
K
PCD3.H114
4)
4
2 I + 1 configurable I
1 CCO
0…16777215 (24-bit) 10 kHz…150 kHz 50 mA 4 mA
2× K
