2.5.2
Saia PCD®Web Panel MB
| Standard devices
TFT displays: LED service life
The STN LCD displays have the system property whereby the displays can only be easily read when viewed from the front while stand-
ing vertically. In addition, the visibility of devices with CCFL backlights is restricted in bright light. Setting the maximum contrast gener-
ally compensates for this. However, this shortens the service life of the LCD display, which therefore needs to be replaced once or twice
over the system lifecycle. The TFT LCD displays built into the Saia PCD® Web Panel MB ensure – using LED backlighting – a long life and
good readability over a long period of time.
S
System properties of TFT LCDs: good readability from any angle and sharp images in bright light
S
System properties of STN LCDs: poor visibility when viewed from an angle
S
Poor visibility in brightly light surroundings
2.5.1
Micro-Browser App for Apple and Android
Technical data
SBC MB light
SBC MB
SBC MB
Energy Manager
SBC MB
Operating system version
> iOS version 3.2
> Android V.2.2
Resolution/pixels
Depends on the devices used
Update management
AppStore
Google Play
Restrictions
No station list
No URL jump
No restrictions
For Energy Manager
only
No restrictions
The Micro-Browser apps breaks the limitations of the industrial world. Most tablets or smartphones are optimized for a long mobile
runtime with high performance. The Micro-Browser App is therefore the ideal way to fill the gap between stationary and mobile areas of
use. This provides the foundation for 24-hour monitoring and direct intervention in system operation.
