Visualization and operating
Saia PCD®Web Panel MB |
Standard devices
Saia PCD® pWeb Panel MB |
with programmable logic controller
Saia PCD®Web Panel MB – Functional HMI |
Visualization and operation with ready-to-use functions
Devices withWindows
®
operating system
Industrial Web Panel withWindows
®
operating system
For complex visualizations, functions can be expanded using
JAVA or .Net components. Access to standard websites
Display sizes 10.4” / 12.1” / 15”
Visualization using Micro Browser technology
2× Ethernet, USB and serial
500 MHz and 1.6 GHz CPU
Web, FTP and VNC server
Windows® CE 6.0 andWindows® eXP
Saia PCD®Web Panel MB | Standard devices
Robust control panel for displaying web visualizations created
with the Saia PG5® Web Editor.
Ready to use immediately without any software installation.
Display sizes 5.0”
/
5.7”
/
7.0” / 10.4”
/
12.1”
Ethernet, USB and serial
FTP server
File system
Windows
®
Devices with Saia PCD® COSinus - Control Operating System
Saia PCD® pWeb Panel MB | with programmable logic con-
troller
The programmable Web Panel combines an Automation Server
for visualization with control and management functions in one
device.
Display sizes 5.7" / 10.4" / 12.1"
2× Ethernet (switch), USB and RS-485
Integrated logic controller
Programmable with Saia PG5®
Automation Server
128 MB of flash memory
One step closer to the application
Functional HMI systems provide functions which support
the user in the implementation of complex applications such
as recording and visualizing data records. Here, the devices
already have an application installed. This can be modified or
expanded.
For more information, see Chapter 4
+
Function
2.1
Overview of types, sizes and resources
