PP26-215 EN11 System catalogue 2014/2015 - page 83

83
saia-pcd.com
A2
PCD7D
Saia PCD® COSinus
Visualization and operating
1
Automationstations
5
4
3
Cabinetcomponents
Dedicatedroom controller
Consumption dataacquisition
2
HMI Visualizationand operating
Saia PCD® Web Panel MB are the core and main part
of the HMI offering.
From simple semi-graphic panels with a classic
keypad to powerful open 15”Windows® eXP touch
panels.
HMI Visualization
and operating
5.0” to 12” device series with SBC Micro Browser and Saia PCD® Automation Server on board.
Firmware and hardware “Made in Switzerland” – Saia Burgess Controls Murten.
Trending, alarming and system images for the operator. Specific websites for maintenance and service.
Local data storage in Excel-compatible CSV format with FTP access for monitoring and logging functions.
Saia PCD® COSinus operating system for automation/MSR technology developed by Saia Burgess Controls.
In addition to the functions of the standard MB panel, a freely programmable logic controller is
integrated. Specific, complex operating and local data processing logic can be realized.
A large number of connected Saia PCD® automation stations can be shown at a higher level.
Device series accessories Š Section 2.5 – page 90
Control panel for web visualizations with Windows®: Saia PCD® Web Panels are specially based on the
requirements of web visualizations and are preconfigured with all the applications and software tools
needed. There is no need for laborious installation and software updates. Saia PCD® Web Panels are ready
to use immediately.
Operation of HMI applications is also possible from multiple connected Saia PCD® automation stations. The
applications are created using Saia PG5® Web Editor and made available in the web server of the Saia PCD®
automation devices for the Web Panel Micro-Browser (MB).
Device series accessories Š Section 2.5 – page 90
Ideal for simple applications and series machines. Programmed using the Saia PG5® HMI Editor software tool.
Classic HMI technology – every HMI device is connected to a control device.
2.2 Saia PCD®Web Panel MB | Web technology Page 85
2.4 Saia PCD® pWeb Panel MB Page 88
2.6 Industrial Web Panel withWindows® operating system Page 94
2.3 Saia PCD®Web Panel MB | Standard devices Page 86
2.7 Overview of semi-graphic displays Page 96
2.1 Overview of types, sizes and resources Page 84
