Automation stations – RIO
Property
PCD3.T665
PCD3.T666
Number of inputs/outputs
64 in base unit, extensible to 256
I/O-module slots
4 in base unit, extensible to 16
I/O-modules supported
PCD3.Exxx, PCD3.Axxx, PCD3.Bxxx, PCD3.Wxxx
Max. number of RIO stations
128
Protocol for data transfer
Ether-S-IO
Ethernet connection
10/100 Mbit/s, full-duplex, auto-sensing, auto-crossing
Default IP configuration
IP address: 192.168.10.100
Subnet mask: 255.255.255.0
Default gateway: 0.0.0.0
USB port for configuration and diagnostics
yes
Program memory
32 kByte
128 kByte
Web server for configuration and diagnostics
yes
Web server for user pages
yes
Onboard file system for web pages and data
512 kByte
BACnet® or L
on
W
orks
®
no
no
Onboard interrupt inputs
2
Onboard RS-485 interface
no
yes
Special modules
for I/O-slot 0 only
---
PCD3.F1xx
for I/O-slots 0…3
(up to 4 modules)
PCD3.H1xx
---
---
PCD3.H1xx counter
PCD3.F26x DALI
PCD3.F27x M-Bus
S-Web alarming/trending
no
no
Watchdog
no
Real-time clock
no
Software clock (not battery-powered)
yes, synchronized by the Manager
Battery
no
Technical data
General data
Supply voltage
24 VDC ±20% smoothed or 19 VAC ±15% full-wave rectified
Capacity of 5 V bus / 24 V bus
max. 650 mA/100 mA
Ambient temperature
0…+55 °C or 0…+40 °C (depending on mounting position)
Storage temperature
–20…+70 °C
Relative humidity
30…95% RH with no condensation
Mechanical strength
according to EN/IEC61131-2
With lean automation, it is not recommended to make full use of the specified limits with regard to the maximum number of stations
per Manager and the maximum number of I/Os per RIO. The following points should be taken into account:
The load on the RIO Manager increases with the rising number of RIO stations. This has an impact on the overall ap-
plication in the RIO Manager.
If there is a large number of RIOs, a sufficiently large amount of PCD media must be reserved on the Manager for the
data transfer.
With a rising number of RIO stations, the build and download process in PG5 is lengthened accordingly. Likewise, the
start-up behavior of the Manager or the entire RIO network is proportionately longer.
Recommendations:
20 Smart RIOs per Manager is a sensible configuration for efficient and problem-free operation, and simple com-
missioning and support.
The Smart RIOs do not have a battery. In the event of an interruption to the power supply, all the data in the RAM memory (registers,
flags, DBs/text) will be lost. Data and parameters that are to remain must either be transferred by the Manager or stored in the RIO’s
flash file system. If this is not possible, the use of a normal controller in place of a Smart RIO is recommended. The user programs are
stored in the flash memory of the RIOs and are retained in the event of an interruption to the power supply.
System properties/limits and recommendations for lean automation
Smart Automation Manager (master station)
Max. 16 RIO stations
PCD3.M2130, PCD3.M2330
Max. 32 RIO stations
PCD1.M212x, PCD3.M3330,
Max. 64 RIO stations
PCD1.M2160, PCD3.M5340, PCD3.M5540, PCD3.M6x40, PCD7.D457VT5F, PCD7.D410VT5F, PCD7.D412DT5F
Max. 128 RIO stations
PCD3.M5560, PCD3.M6560, PCD3.M6860
