S-Web Editor
2
Communication &
Interaction
SBC S-Web Technology
1
SBC Software
3
SBC S-Web Technology
3.6
Products/tools
Using a SBC S-Web systemwith devices belonging to the existing infrastructure
Each PC can be used to visualise the Saia PG5® Web HMI pages. The web HMI pages
created using the Web Editor are interpreted by a Java applet in the browser on the
PC.
Office PC with browser
and Java on board
Operating system
Browser
Java Virtual
Machine JVM
Any device made available by an operating system with the support of a browser
and Java engine can be used with SBC S-Web.
PC Software
Saia PG5®Web Editor
Efficient engineering
of graphical
interactive interfaces
SBC Micro Browser
Dedicated web browser
for automated systems
with SBC S-Web. Integrated in
Saia PCD® Web Panel MB
SBC Micro Browser Apps
for “third party hardware”
`
Apple App
`
Android App
SBC.Net
Gateway and proxyserver
functions
Detailed information
in Chapter B1 Software
Detailed information
in Chapter A2
Operation and Monitoring
Detailed information
in Chapter A1.1
Saia PCD® system description
S-Web accessories
Memory for the automation
station to store historical
data.
Base module for the SD
Flash memory
PCD3.R600
PCD2.R6000
SD-Flash memory
512 MByte
PCD7.R-SD512
1024 MByte
PCD7.R-SD1024
Memory module
PCD7.R5xx
Industrial web panel withWindows operating system
Immediately operational without software installation
`
Specially designed for use with SBC S-Web technology for
automated systems.
`
SBC.Net is pre-installed
`
Ideal for linking Windows applications or proprietary
Microsoft .Net applications to the automation world.
Detailed information can be found in chapter A2 "Operation and monitoring".
