SBC S-Web Technology
AMC wanted to refurbish and extend the controls systems, step by step, over
several years, without fearing the costs and difficulties of possible changes
in automation station generation. They started using Saia PCD® controllers
in their buildings, processes and utilities in 2000. More than 10 years later,
the choice is still considered as the right one. This is supported by the transparent
integration of the newest Saia PCD® generation, the general use of Ethernet, data
logging on flash and the reliability of the installed base. The communication
capabilities of Saia PCDs which make it possible to connect to all systems make
the life of the system integrator simpler.
Academic Medical Centre
Amsterdam/Netherlands
One of the top ten academic hospitals in the world relies on Saia PCD® controllers for a better climate
and reduced energy consumption
European Research Centre CERN
Geneva/Switzerland
The entire enormous CERN site consisting of 430 operational buildings relies entirely
on SBC S-Web.
Thanks to Web+IT standards, it has no need for a dedicated central office or master control/
management layer.
Around 10,000 people work in the 430 buildings at CERN. Each building is fully independent.
SBC S-Web forms their control/management layer. There is no need for dedicated SCADA
software/PC hardware. The existing and already mastered CERN Web+IT technology is sufficient
for integrating the consumption data across the site and for monitoring purposes. Operation of
the building technology does not require the purchase of, installation of or training on dedicated
Windows software. Automation projects are awarded by CERN throughout Europe. Thanks to
SBC S-Web, system integrators all over Europe are able to realise autonomous projects for CERN or
improve existing systems. There is no need to involve or reintegrate a central BMS application.
With S-Web, CERN benefits from a technology it discovered itself in 1989.
Source: Wikipedia
S
The local conditions in the individual parts of the system
and building were resolved in this application using S-Web.
A total of 310 automation stations (Saia PCD®) are integrated
in the property automation system. The entire clinic
is operated, controlled and managed as a functional unit.
In hospitals, the high volume of visitors and the ventilation/
cooling system are “mission critical”. In this respect it
is therefore preferable to operate a central iFIX 4.0 PC/
Windows-based control/management system parallel
to SBC S-Web. SBC S-Web is not able to make the classic
SCADA software completely superfluous in this instance.
20 touch panels with micro-browser
iFix 4.0
