Saia PCD®
L1
L2
L3
N
(PEN)
D /D
N
L
N
L
L1
L2
L3
N
(PEN)
S-Monitoring
1
5
2
3
4
Dedicated
room controller
HMI Visualization
and operating
Automation
stations
Cabinet
components
Consumption data
acquisition
4.4.2
Saia PCD® energy meters with SBC S-Bus interface
The energy meters with integrated S-Bus interface offer all relevant data such as energy, current, voltage, out-
put (active and reactive) and cosφ, which can be read out through the bus connection.The serial S-Bus interface
(based on RS-485) can be connected directly to the Saia PCD® range of devices. For this connection, there are
ready-made FBoxes for every meter type, which are available free of charge. The S-Bus energy meters are also
available in a two-way design (bidirectional). On the display, the bus address can be set and the energy, current,
voltage and active output can be read directly.
ALD1 / AWD1
ALE3
AWD3 / AWC3
ALD1
D5FS00A2A00
ALD1
B5FS00A2A00
ALD1
D5FS00A3A00
ALD1
B5FS00A3A00
AWD1
D5WS00A2A00
ALE3
D5FS10C2A00
ALE3
B5FS00C2A00
ALE3
D5FS10C3A00
ALE3
B5FS00C3A00
AWD3
D5WS00C2A00
AWD3
B5WS00C2A00
AWD3
D5WS00C3A00
AWD3
B5WS00C3A00
AWC3
D5WS00C2A00
Tariff
1 tariff
y y y y y
–
y
–
y y y y y y
2 tariffs
– –
–
– –
y
–
y
– – – – – –
Meter type
Unidirectional design
y
–
y
–
y y
–
y
–
y
–
y
–
y
Bidirectional design
–
y
–
y
– –
y
–
y
–
y
–
y
–
Approvals
With MID
– –
y y
– – –
y y
– –
y y
–
Without MID
y y
– –
y y y
– –
y y
– –
y
Rated/
Max. current
I
min
= 0.01 A, I
N
= 1 A, I
max
= 1.2 A
– – – – – – – – – – – – –
y
I
min
= 0.05 A, I
N
= 5 A, I
max
= 6 A
– – – –
y
– – – –
y y y y
–
I
min
= 0.25 A, I
N
= 5 A, I
max
= 32 A
y y y y
– – – – – – – – – –
I
min
= 0.5 A, I
N
= 10 A, I
max
= 65 A
– – – – –
y y y y
– – – – –
Measurement type
Direct measurement
y y y y
–
y y y y
– – – – –
Conversion up to 300 A
– – – – – – – – – – – – –
y
Conversion up to 500 A
– – – –
y
– – – – – – – – –
Conversion up to 1500 A
– – – – – – – – –
y y y y
–
Operating
voltage
230 VAC, 50 Hz
y y y y y
– – – – – – – – –
3 × 230/400 VAC, 50 Hz
– – – – –
y y y y y y y y y
Partial meter
Resettable
y
–
y
– –
y y y y y
–
y
–
y
FBoxes available for
every S-Bus meter type
SBC S-Bus
Bus system Serial RS-485 interface
Log
S-Bus data mode
Transmission
rate
2400, 4800, 9600, 19,200, 38,400,
57,600, 115,200 Baud. The transmission
rate is detected automatically.
Bus cable
Twisted, shielded, 2 × 0.5 mm
2
,
max. 1,200 m
Response time Write:
up to 60 ms
Read:
up to 60 ms
Technical data
Converter meter
three-phase AWD3
Direct measurement
three-phase ALE3
Converter meter
single-phase AWD1
Connection diagramwith an S-Bus energy meters
Direct measurement
single-phase ALD1
