Dedicated room controller
High energy efficient room automation
The combinable room control system can be used for multi-section room automation whereby with the demand-based control and
communication to the primary system can reach the highest energy efficiency classes of DIN EN 15232 for the entire building automa-
tion system.
Energy efficiency of building energy effi-
ciency classes in accordance with EN 15232
Class A:
– High energy efficiency room automation
and cross linked trades
(application segment)
Class B:
– Optimised solutions for each trade,
partially cross linked
Class C:
– Standard room automation
Class D:
– No room automation, not energy efficient
Light and shade
extension module
PCD7.L62x
Control devices
Presence detection
Brightness measurement
PCD7.L665
Internal RC-Bus
PCD7.L600-1…604-1
S
erial
S-N
et
PCD7.L600-1…604-1
S
erial
S-Net
PCD3.M5560
PCD7.L610…616
L
on
W
orks
®
PCD7.L644
PCD7.L660
PCD7.L645
Networked room automation for an optimum synergy between the sections
Temperature control based on demand control
Combined air quality and temperature control
