Consumption data
acquisition
With the field devices of the S-Monitoring system, electrical
energy is measured and signals from water, gas and heating
meters are captured. The data is automatically further
processed and visualised clearly by the S-Monitoring
application. Thus, the system generates a high degree
of transparency with regard to resource consumption.
This works from just a few measuring points up to
thousands of measuring points in distributed properties.
Capturing, visualising and
processing consumption data
S-Monitoring makes energy and consumption management easy. Ready-to-use direct from the packaging,
it can be used without complicated configuration and programming. Yet it can subsequently be customized to
meet to special requirements – it is a system that grows with you.
4.1
System overview
Page
114
Collect, convert and transmit S0 pulses: With the PCD7.H104 pulse counter modules, non bus-capable meters
can also be integrated in an S-Monitoring system.
4.2
Saia PCD® S0 pulse counter
Page
116
With the PCD7.H108S, not only S0 pulses, but also up to four temperature measurement points can be
integrated in one Saia PCD® automation system.
4.3
Saia PCD® S0 pulse counter with temperature inputs
Page
117
Saia Burgess Controls, or SBC for short, is a European market leader in bus-capable energy meters for secondary
measurement of electrical energy data: for machines, plants and building components.
4.4
Saia PCD® energy meters
Page
118
The E-Monitor combines data capture, visualisation and logging in one compact control panel.
This makes it easy to start data capture.
4.6
Saia PCD® E-Monitor
Page
128
The E-Controller with S-Monitoring function combines data capture, visualisation and logging of energy
consumption in one compact device. Via the inputs and outputs, it is possible to intervene in processes for
regulation.
4.7
Saia PCD® E-Controller
Page
130
S-Monitoring is an integral part of the COSinus operating system and is integrated in all new Saia PCD®
controllers. It makes it possible to capture consumption data automatically without time-consuming
programming and saves it on the file system.
4.5
Basic functions of the S-Monitoring application
Page
126
