HMI Visualization
and operating
1
Automation
stations
5
4
Cabinet
components
Consumption data
acquisition
3
Dedicated
room controller
Dedicated room controller
Control devices
PCD7.
L660
PCD7.
L662
Receivers
PCD7.
L661
PCD7.
L663
PCD7.
L665
*
PCD7.
L666
*
RC-Bus
max. 50 m cable length
Wall mounted control device
Including for fixed installation
---
---
Communication / IR (infrared)
Unidirectional
•
---
Communication / radio
Bidirectional
---
•
Temperature sensor
•
•
---
---
Setpoint value adjustment
•
•
•
•
Presence control
•
•
Motion sensor
Fan control
•
•
•
•
Light and shade
•
•
•
•
Brightness sensor
---
•
•
Supply voltage control device
2 × AAA 1.5 V Micro
---
---
Temperature range
+5…45 °C, 80% r.H.
Portable room control units with display and function keys
Direct connection of the room control units from the external supplier via L
ON
W
ORKS
®
System requirements:
`
Room controller with L
ON
W
ORKS
® interface.
`
For making additional connections to the automation station,
the – PCD3.M– PCD2.M5– PCD1.M2 can be connected via the
L
ON
over IP or via an external FTT10/IP router.
L
ON
W
ORKS
®
Room
Router
EnOcean radio receiver PCD7.L651
*
for connecting Thermokon room control devices and EnOcean wireless switches
More detailed information on the compatibility of the EnOcean receivers is contained in the PCD7.L651 manual
max. 50 m cable length
Example of EnOcean wireless switch for controlling lights and Venetian
blinds (compatible with various control programs of various manufacturers)
Example of EnOcean room control devices for controlling HVAC
PCD7.L662-CT
*
Configuration tool to connect PCD7.L666 to PCD7.L662
S
ERIAL
S-Net
HTTP direct
Room
Individual solutions using web-based room control units
System requirements:
`
Room controller with communication to PCD via S-Net, L
ON
W
ORKS
®.
`
PCD with corresponding interface and interface for connecting
to the desired control
device, e.g. webpanel, PC,
iPhone, etc.
Communicative room control units
RC-Bus
