SBC Software
Web Editor window: Document Outline
Web Editor window: Properties
The Web Editor includes a transparent and adjustable workspace for efficient operation. The workspace essentially comprises the menu/
instruction bar, the View Editor (drawing area) and windows. Thanks to docking window technology, the user can freely position and
show/hide the windows as he requires.
The most important windows are explained here:
Web Editor window: Solution
The Solution shows the
project and file structure. This
folder can contain multiple
Web Editor projects with
various data types. The file
types are shown clearly in an
orderly tree structure.
The Document Outline
window provides an
overview of the structure of
the current view.
With this window, an element
can be selected directly,
regardless of its group or
level.
Web Editor window: Symbols
Web Editor window: Layers
Symbols are taken over from
the configured PG5 project
path and updated automati-
cally.
To find symbols quickly, the
window has a search
function.
This window provides an
overview of all layers in the
view currently open. Layers
can be created, moved or
deleted. All layers, including
the background and
foreground view, can be
hidden for additional clarity.
In the “Properties”window, the properties and behavior of objects at runtime are quickly and easily
configured with just a few clicks.
The window is subdivided into four areas:
General
– View settings (depending on conditions)
Actions
– Configuration of results (when holding down, when releasing)
– Function key
Access
– Settings for access control
Other
– Element name and comments
