On-board inputs/outputs
Inputs
6 Digital inputs (4 + 2 interrupts)
15 - 30 VDC, 8 ms / 0.2 ms input filter
Terminal X1
2 Analogue inputs, selectable via DIP switch,
preconfigured for Ni1000 in the default setup
–10…+10 VDC, 0…+/–20 mA,
Pt1000, Ni1000, Ni1000 L&S, 0…2.5 kΩ, 12 Bit resolution
Terminal X1
Outputs
4 Digital outputs
24 VDC / 0.5 A
Terminal X0
1 PWM output
24 VDC / 0.2 A
Terminal X0
selectable/configurable via PG5
4 Digital inputs or outputs,
preconfigured for digital inputs in the default setup
24 VDC / data such as digital inputs or digital outputs
Terminal X0
1 Watchdog relay or as make contact
48 VAC or VDC, 1 A
With DC turn-on voltage a free-wheeling diode should be connected
in parallel to the load
Terminal X3
General data
Operating voltage
24 VDC, –20/+25 % max. incl. 5 % ripple (in accordance with EN/IEC 61131-2)
Battery for data backup (replaceable)
Lithium battery with a service life of 1 to 3 years
Operating temperature
0…55 °C
Dimensions (W × H × D)
142 × 142 × 60 mm
Mounting type
Top-hat rail according to DIN EN 60715 TH35 (1 × 35 mm) or on a level surface
Protection type
IP 20
Capacity 5 V/+V (24 V) internal
max. 500 mA/200 mA
Power consumption
typically 12 W
Automation Server
Flash memory, file system, FTP and web server, e-mail, SNMP
Installation notes and recommendations
Assembly in the distribution board
The Saia PCD1.M0160E0 has the dimensions 142 × 142 × 60 mm excluding terminals and connections.
For easy assembly, a gap of 55 mm above the DIN rail and 75 mm below it is recommended.
Ethernet cable
For installation in the sub-distributor, an angled or flexible network cable (e.g. SlimWire PRO) is recommended.
With installation of a conventional network cable, assembly of the sub-distributor cover cannot be guaranteed.
Technical data
PCD1.M0160E0
Memory and file system
Program memory, DB/text (Flash)
1 MB
User memory, DB/text (RAM)
1 MB
User Flash file system onboard
128 MB
Integrated communication
Ethernet connection (2 port switch)
10/100 Mbit/s, full-duplex, auto-sensing, auto-crossing
Yes
USB port
USB 1.1 device 12 Mbit/s
Yes
RS-485 (terminal X3)
up to 115 kbit/s
Yes
Overview of Saia PCD® E-Controller
Automation Server
integrated in base unit
¼
For interface options and accessories, see Section 1 “Automation stations – PCD1”
