Communication & interaction
Ethernet
PPP: Point to Point Protocol
This is a protocol established along a communication
route from one point (location) to another. PPP
is a protocol that is mainly used to transport TCP/IP
protocols via a serial cable or modem connection.
In order to meet the greater security needs demanded
when dialling into company networks or systems with
critical tasks, CHAP (Challenge Authentication Protocol)
was introduced.
The user has access to the web and FTP server
via a Telekom interface (PSTN, ISDN, GSM/GPRS)
in the Saia PCD® controller. This also applies
to applications with more economical devices and
no Ethernet connection.
Standard
RFC-1661
Authentication
PAP, CHAP and MS-CHAP
Simultaneous PPP connections
Only one PPP connection (client or server) can be active per Saia PCD® controller.
PPP via Ethernet
No
IP protocol
Telecom
Web browser
Post pox
PCD2.M5
FTP client
PG5/SCADA
PCD3.M
Internet
Intranet
The email function and integrated SMTP client (Simple Mail Transfer Protocol) can be used to send PCD device process and system
information to an email server. This enables alarm, service and status messages, log data or any form of process information to be sent
via email to a control centre or service personnel.
FBoxes
FBoxes are available for sending emails
using the application program. The email
function is configured (mail server, port
number, user and password, etc.) via
these FBoxes. It is also possible to send
file attachments (e. g. log data) of
up to 1 MByte.
Technical data
SMTP Standard
RFC 821, 822
Standard port number
25 (adjustable) + 587
Server authentication
«AUTH LOGIN» or «AUTH PLAIN» in accordance with RFC 2595 (unencrypted transmission of password)
Email format
Text or HTML
Interfaces
Ethernet, serial RS-232 with PPP
SMTP: Protocol for sending emails
PLC data and file system
E-mail client
Files from file
system
PCD media text
messages
E-mail server
E-mail client
Internet
Intranet
Telecom
Ethernet
IP protocols
PPP
RS-232
