SBC Software
3
SBC S-Web Technology
2
Communication &
interaction
Communication & interaction
Compact modular
Compact
PCD3
compact
PCD3.WAC
Wide area controller
PCS1
I/O data points
PCD3.M2030V6
PCD3.M2130V6
PCD3.M2330A4T1
PCD3.M2330A4T3
PCD3.M2330A4T5
PCD3.M2230A4T3
PCS1.C42x
PCS1.C62x
PCS1.C82x
PCS1.C88x
On-board (data points)
38 38 14 14 14 14 19 30 44 44
Optional I/O slots via expansion modules PCD3.Cxxx
1)
4
4
4
4
4
4
---
---
---
---
Maximum number of I/Os
1)
102 102 78 78 78 78 19 30 44 44
Maximum number of interfaces (incl. PGU)
3
4
5
5
5
4
3
3
3
4
On-board interfaces
RS-232, PGU up to 115 kBit/s (Port #0)
---
---
---
---
---
---
● ● ● ●
USB 1.1 device, PGU
● ● ● ● ● ●
---
---
---
---
Ethernet TCP/IP 10/100 MBit
Fullduplex, autosensing
---
1
1
1
1
---
---
---
---
---
RS-485 up to 115 kBit/s (Port #2) or Profi-S-Net up to 187.5 kBit/s
(Port #2)
●
●
●
●
●
●
●
●
●
●
●
●
---
---
---
---
---
---
---
---
L
on
W
orks
® FTT10
---
---
---
---
---
---
---
---
---
●
Modem P=PSTN, I=ISDN,
PCD: G=GSM/GPRS,
PCS: G=GSM
---
---
P
I
G G P, I, G P, I, G P, I, G P, I, G
Optional interfaces
Modbus RTU serial or IP
● ● ● ● ● ●
---
---
---
---
Slot for PCD7.F1xxS (A1)
1
1
1
1
1
1
---
---
---
---
Uses an external modem via RS-232 interfaces
● ●
---
---
---
---
● ● ● ●
1)
I/O slots can be fitted with I/O modules as required (see pages
29/30 and 48/49). The number of data points which can
be processed by a PLC depends on the number of I/O data points
per module. A max. of 16 data points is available per module.
A PCD can therefore process a maximum number of data points
of 64 I/O slots × 16 data points/slot = 1024 I/O data points.
4)
The PCD2.F2400 and PCD3.F240
L
on
-FTT10
modules are only
available on the following controllers:
PCD1.M2020, PCD1.M2120, PCD1.M2160, PCD1.M2110R1,
PCD3.M5560, PCD3.M6560, PCD3.M6860
5)
Galvanically connected
6)
Galvanically insulated
2)
A PCDx.R56x memory module is always required to use BACnet®.
Controllers without Ethernet support BACnet MS/TP using
optional PCD2.F2150 or PCD3.F215 communication modules.
Controller
Memory
module
Max. free
I/O slots
PCD3.M3xx0 PCD3.R56x
3
PCD3.M5xx0 PCD7.R56x
4
PCD2.M5xx0 PCD7.R56x
4
PCD1.M2xx0 PCD7.R56x
2
PCD1.M0xx0 PCD7.R56x
---
PCD1.Room PCD7.R56x
1
3)
It is only possible to operate BACnet®-IP and L
on
®-IP in parallel
on the PCD3.M5560, PCD3.M6560 and PCD3.M6860 controllers.
