Communication & interaction
BACnet®
* For the availability see chapter C2 Product status
Order information
Efficient engineering through automatic generation
The application FBox libraries from DDC Suite v2.0 and Room
Controller v2.0 onwards give the system integrator even more
convenience. An FBox parameter can be used to automatically
generate a suitable BACnet® configuration when creating
the application program. All necessary settings take place within
the application FBoxes.
Freely programmable BACnet configuration
The application can be created as usual using the
Saia PG5® Controls Suite.
The BACnet® configurator it contains allows the completely free
parameterisation of all BACnet® objects. This makes it possible
to solve all conceivable tasks.
Clearly structured dialogs make the parameterisation
of schedules, trends and alarms easy to understand.
BACnet® configurator in the Saia PG5® Controls Suite
PG5 FUPLA Editor
BACnet® Adjust Window
Automatic creation of
BACnet® objects and PCD resources
using FBoxes and templates.
EDE file export for
connecting the PCD to
master SCADA systems.
EDE file import
for the simple creation
of BACnet® clients
Model
Description
PCD7.R560
BACnet® options module for PCD1.M0, PCD1.M2, PCD2.M5, PCD3.M5 and PCD3.M6
for slot M1 or M2
PCD7.R562
BACnet® options module for PCD1.M0, PCD1.M2, PCD2.M5, PCD3.M5 and PCD3.M6
for slot M1 or M2 incl. 128 MB for program backup and file system
PCD3.R560 BACnet® options module for PCD3.M3, PCD3.M5 and PCD3.M6 for I/O slot 0…3
PCD3.R562
BACnet® options module for PCD3.M3, PCD3.M5 and PCD3.M6 for I/O slot 0…3
incl. 128 MB for program backup and file system
