SBC Software
Analysis of trend data (PChart)
If the user wishes to display or export trends, however they have
been compiled, PChart is the tool to use. The trend data can be
displayed in a variety of colors and different scales.
MALM ESPA 4.4.4
With this module, alarms can be forwarded to telecommunica-
tions systems with an ESPA 4.4.4 interface (serial, type RS-232), to
be output to the display of a telephone within the local
telephone network.
pSMS
With a GSM-compatible modem (not included), SMS messages
can be received and their content assessed according to a
specification (e.g. to acknowledge alarms or modify values).
SNMP Manager
Driver to monitor network components that provide SNMP
services, such as routers or controllers. The values polled
(depending on parameters set) are integrated into the Visi.Plus
database, where they can be processed further (e.g. for history
data or alarms).
Add-on programs
MALMVoice
When an alarm occurs, a voicemail message (sound file in WAV
format) can be played back via telephone. The person called can
then use the same call to acknowledge the alarm by entering a
sequence of numbers (requires a DTMF-enabled telephone).
ESPA 4.4.4 (RCV)
Messages transmitted by telecommunications systems with an
ESPA 4.4.4 interface (serial, type RS-232) can be implemented as
alarm messages by Visi.Plus and used for further processing and
logging.
pCalc
Calculations for energy analysis and system monitoring,
up to 1,000 formulas with 16 variables each.
Mobile Alarm (MALM)
Remote alarms via email/SMS.
When monitoring technical building installations it is necessary to
guarantee that, in the absence of service personnel, fault
messages are forwarded quickly and safely. Direct diagnosis of the
fault message is also possible via remote dial-in, thus avoiding
unnecessary journeys by service personnel. The alarm is sent via
SMS or email.
System requirements
Visi.Plus requires the following as a minimum:
Windows 2000, Windows XP, Windows XP Embedded,
Windows Vista, Windows 7 (32 / 64-bit versions)
Windows Server 2003, Windows Server 2008
(32 / 64-bit versions)
Pentium 1 GHz PC
512 MB RAM (the higher the number of DMS data points, the
more memory that is required)
Hard disk with at least 60 MB free memory (for the installation)
CD-ROM drive (poss. external data backup (CD writer))
