SBC S-Web technology
SBC Software
2
Communication &
Interaction
1
SBC Software
Type
Saia Visi.Plus packages in German and English (1 license per project)
Visi.Plus Engineering Edition
(Engineering Edition is part of each PG5 licence)
PCD8.VP-DEMO
Visi.Plus Demo – Demo package
PCD8.VP-MINI
Visi.Plus Mini – Mini package
Data management system, database system, graphical editor, engineering tool, scheduler program, trend and alarm capture
and S-Driver for 1,000 data points (approx. 65 hardware data points)
PCD8.VP-BASIC
Visi.Plus Basic – Basic package
Data management system, database system, graphical editor, engineering tool, scheduler program, trend and alarm
capture, MALM remote alarms via pager/SMS/e-mail, PRT access logging and S-Driver for 10,000 data points (approx. 650
hardware data points)
PCD8.VP-STD
Visi.Plus Standard – Standard package
Data management system, database system, graphical editor, engineering tool, scheduler program, trend and alarm
capture, MALM remote alarms via pager/SMS/e-mail, PRT access logging, pChart trend displays, Web Server 2 and S-Driver
for 100,000 data points (approx. 6500 hardware data points)
PCD8.VP-UPGRADE
Visi.Plus Update
– Version update (according to customer Visi.Plus package)
S-Driver options – Add-on for Visi.Plus packages
PPCD8.VP-SBUS10K
Option for Visi.Plus packages
S-Driver for 10,000 additional data points (approx. 650 hardware data points)
PCD8.VP-SBUS25K
Option for Visi.Plus packages
S-Driver for 25,000 additional data points (approx. 1,625 hardware data points), not possible with the Mini package
PCD8.VP-SBUS50K
Option for Visi.Plus packages
S-Driver for 50,000 additional data points (approx. 3,250 hardware data points), not possible with the Mini package
PCD8.VP-SBUSUL
Option for Visi.Plus packages
S-Driver for unlimited data points, not possible with the Mini package
Module options – Add-on for Visi.Plus packages
PCD8.VP-GE2
GE2 – Graphical editor
Runtime system, two additional operator stations
PCD8.VP-GE5
GE5 – Graphical editor
Runtime system, five additional operator stations
PCD8.VP-GE10
GE10 – Graphical edito
r Runtime system, ten additional operator stations
PCD8.VP-GEUL
GEUL – Graphical editor
Runtime system, unlimited operator stations
PCD8.VP-PRT
PRT
– Access logging (included in Basic and Standard package)
PCD8.VP-PCHART
pChart
– Trend display tool
Each user (1…10) costs one full pChart license (one user included in the Standard package)
PCD8.VP-PCALC
pCalc
– Calculations for energy analysis and system monitoring, up to 1,000 formulas with 16 variables each
PCD8.VP-MALM
MALM
– Remote alarms via pager/SMS/e-mail (included in Basic and Standard package)
PCD8.VP-MALMVOICE
MALMVoice
– Transmission of voice mail with acknowledgement via DTMF (add-on option for MALM)
PCD8.VP-MALMESPA
MALM ESPA 4.4.4
– Remote alarms (sending) via ESPA protocol (add-on option for MALM)
PCD8.VP-ESPA
ESPA 4.4.4
– Receive alarms and messages via ESPA protocol to Visi.Plus
PCD8.VP-PSMS
pSMS
– Receive and evaluate SMS via GSM modem (GSM modem is not included in the scope of delivery)
PCD8.VP-SNMP
SNMP driver
to monitor network components with SNMP polling
PCD8.VP-WEB2
Web Server 2
– for 2 additional simultaneous connections
PCD8.VP-WEB5
Web Server 5
– for 5 additional simultaneous connections
PCD8.VP-WEB20
Web Server 20
– for a maximum of 20 simultaneous connections
Other drivers
PCD8.VP-OPC1
OPC1
– OPC client Client for 250 data points
PCD8.VP-OPC2
OPC2
– OPC client Client for 1,000 data points
PCD8.VP-OPC3
OPC3
– OPC client Client for 10,000 data points
BACnet
– Driver*
Order information | Saia Visi.Plus
Three basic Visi.Plus versions are available to system integrators. Depending on the job requirements and the complexity of the systems,
the appropriate package for the client can be deployed and extended with add-on modules.
* In preparation, see section C2 Product status
