PP26-215 EN12a SBC System catalogue 2015/2016 - page 27

27
saia-pcd.com
PCD
3
Automation stations – Saia PCD3
5
Switch cabinet
components
4
Consumer
data acquisition
3
Dedicated
room controllers
2
Operation
and monitoring
1
Automation
stations
Saia PCD3 digital input and output modules
The digital I/O modules can be easily plugged into the Saia PCD3 Basis CPU or an appropriate module holder. In addition to inputs for
various voltage levels, digital outputs are provided with both transistor construction and as mechanical relays. This means that electrical
isolation from the switching electrical circuit can be achieved easily and reliably.
Digital input modules
Type
Number of I/Os
Input voltage Output switching capacity
DC AC
Input delay Electrical
isolation
Internal current draw
5 V-Bus 
1)
+ V-Bus 
2)
I/O connector
type 
3)
PCD3.E110
PCD3.E111
PCD3.E112
PCD3.E116
8 I
8 I
8 I
8 I
15…30 VDC
15…30 VDC
7.5…15 VDC
3.5…7  VDC
---
---
8 ms
0.2 ms
9 ms
0.2 ms
---
24 mA
24 mA
24 mA
24 mA
---
A
A
A
A
PCD3.E160
PCD3.E161
16 I
16 I
15…30 VDC
15…30 VDC
---
---
8 ms
0.2 ms
---
10 mA
10 mA
---
D
D
PCD3.E165
PCD3.E166
16 I
16 I
15…30 VDC
15…30 VDC
---
---
8 ms
0.2 ms
---
10 mA
10 mA
---
C
C
PCD3.E500
6 I
80…250 VAC
---
---
20 ms
1 mA
---
A
PCD3.E610
PCD3.E613
8 I
8 I
15…30 VDC
30…60 VDC
---
---
10 ms
9 ms
24 mA
24 mA
---
A
A
Digital output modules
Type
Number of I/Os
Input voltage Output switching capacity
DC AC
Input delay Electrical
isolation
Internal current draw
5 V-Bus 
1)
+ V-Bus 
2)
I/O connector
type 
3)
PCD3.A200
PCD3.A210
4 A, relay (make) 4 A, relay
(break)
---
2 A/50 VDC
2 A/50 VDC
2 A/250 VAC
2 A/250 VAC
---
15 mA
15 mA
---
A
A
PCD3.A220
6 O, relay (make)
---
2 A/50 VDC
2 A/250 VAC
---
20 mA
---
A
PCD3.A251
8 O, relay
(6 changeover + 2 make)
---
2 A/50 VDC
2 A/48 VAC
---
25 mA
---
C
PCD3.A300
6 O, transistor
---
2 A/10…32 VDC
---
---
---
20 mA
---
A
PCD3.A400
8 O, transistor
---
0.5 A/5…32 VDC
---
---
---
25 mA
---
A
PCD3.A410
8 O, transistor
---
0.5 A/5…32 VDC
---
---
24 mA
---
A
PCD3.A460
PCD3.A465
16 O, transistor
16 O, transistor
---
0.5 A/10…32 VDC
0.5 A/10…32 VDC
---
---
---
10 mA
10 mA
---
D
C
PCD3.A810
Manual operation
4 O, relay (2 changeover +
2 make)
---
2 A/50 VDC
2 A/50 VDC
5 A/250 VAC
6 A/250 VAC
---
40 mA
---
F
Digital input/output modules
Type
Number of I/Os
Input voltage Output switching capacity
DC AC
Input delay Electrical
isolation
Internal current draw
5 V-Bus 
1)
+ V-Bus 
2)
I/O connector
type 
3)
PCD3.A860
Light and shade
2 O, relay (make) 2 I
15…30 VDC
---
12 A/250 VAC 8 ms
18 mA
---
G
H
PCD3.B100
2 I + 2 O + 4 selectable I or O I: 15…32 VDC 0.5 A/5…32 VDC
---
8 ms
---
25 mA
---
A
PCD3.B160
16 I/O (configurable)
I: 24 VDC 0.25 A/18…30 VDC
---
8 ms or
0.2 ms
---
120 mA
---
2× K
3)
Plug-in terminal blocks are included with I/O modules. Spare terminals, ribbon connectors with system cables and separate
terminals are ordered as accessories (see pages 34 and 160).
Fast counter modules (only for I/O slots with fast SPI bus)
Type
Number
of counters
Inputs per counter
Outputs per
counter
Counting range
Selectable digital
filter
Current draw 5 V-
Bus 
1)
+ V-Bus 
2)
I/O connector
type
3)
PCD3.H112
2
2 I + 1 configurable I
1 CCO
0…16 777215 (24 Bit) 10 kHz…150 kHz 50 mA 4 mA
K
PCD3.H114
4
2 I + 1 configurable I
1 CCO
0…16 777215 (24 Bit) 10 kHz…150 kHz 50 mA 4 mA
2× K
Overview of the internal bus capacity of the module holders
Capacity
PCD3.Mxxx0
PCD3.Txxx
PCD3.C200
1)
Internal 5V
600 mA
600 mA
1500 mA
2)
Internal +V (24 V)
100 mA
100 mA
200 mA
The electrical requirement of the internal +5V and +V bus for the I/O modules is
calculated in the PG5 2.0 Device Configurator.
