KFE102 / 103 / 300 / 302
KFT100 / 200
`
Voltage and current monitoring, three-phase asymmetry
monitoring
`
Phase order, phase failure
`
Three-phase voltage monitoring
`
230 VAC, 3 × 400 VAC 50/60 Hz
`
1 changeover contact
`
Motor monitoring by PTC
`
PTC short-circuit monitoring
`
PTC cable-break monitoring with memory func-
tion (KFT200)
`
230 VAC
`
1 relay (NO contact, KFT100)
`
2 relays (changeover contact, KFT200)
5.7
SBC Monitoring relays
KFE102 KFE300
KFE302
KFT100 KFT200
Series
KFE102/103/300/302
KFT100/200
Order reference
KFE102NE1N
KFE103NE1N
KFE300NE9N
KFE302NE9N
KFT100JE1N
KFT200KE1N
Functions KFE102/103/300/302
Voltage monitoring
Ɣ
---
---
---
---
---
Current monitoring
---
Ɣ
---
---
---
---
Monitors phase loss, order, asymmetry and under voltage
---
---
Ɣ
---
---
---
3-phase voltage monitoring (AC)
---
---
---
Ɣ
---
---
Memory function
Ɣ
Ɣ
---
Ɣ
---
---
Settings KFE102/103/300/302
Parameterizable, LCD display
Ɣ
Ɣ
---
---
---
---
Analog
---
---
Ɣ
Ɣ
---
---
Functions KFT100/200
Motor monitoring by PTC
---
---
---
---
Ɣ
Ɣ
Short-circuit monitoring in the PTC measuring circuit
---
---
---
---
Ɣ
Ɣ
Cable-break monitoring in the PTC measuring circuit
---
---
---
---
Ɣ
Ɣ
Memory function
---
---
---
---
---
Ɣ
Reset KFT100/200
automatic
---
---
---
---
Ɣ
---
manual or automatic
---
---
---
---
---
Ɣ
Operating voltage
230 V
AC
Ɣ
Ɣ
---
---
Ɣ
Ɣ
3 × 400 V
AC
---
---
Ɣ
Ɣ
---
---
Output
1 relay (NO contact)
---
---
---
---
Ɣ
---
1 relay (changeover contact)
Ɣ
Ɣ
Ɣ
Ɣ
---
---
2 relays (changeover contact)
---
---
---
---
---
Ɣ
Function control
LED display
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Dimensions
KFE
KFT100
KFT200
