Automation stations – the basics
1
Automation
stations
Programmable for measuring, regulation and control
devices. Modular series consisting of industrial quality
CPU, I/O and communication modules with a service
life that will last for decades.
The application software can be simply and reliably
adapted and expanded throughout its service life.
It can be used for all device series (Saia PCD1, 2 and 3).
Automation stations
Presentation of the Saia PCD® COSinus control operating system – hardware structure – program execution
– memory system and service capability.
Up to 1023 I/Os – up to 13 simultaneously operated communication interfaces.
18 basic I/Os which can be expanded to max. 50 I/Os with 2 optional I/O modules – up to 8 simultaneously
operated communication interfaces.
External dimensions independent of the type and number of the integrated hardware modules.
Expandable system up to 1023 I/Os – up to 15 simultaneously operated communication interfaces.
E-Line product line for specific applications in very confined spaces.
Programmable I/O modules
I/O modules
Communication modules and gateways
1.2
Saia PCD3 – modular cartridge construction
Page
1.4
Saia PCD1 – modular, expandable, compact CPU
Page
1.3
Saia PCD2 – modular technology with a compact design
Page
1.5
Saia PCD1 E-Line
– compact design for electrical distributors
Page
1.1
Basic system properties
Page
Saia PCD3.Mxx6x as high power CPU
Saia PCD3.M5xxx as standard control device
Saia PCD3.T66x remote I/O stations
Saia PCD3.M3xxx as the most compact base unit
Saia PCD3.M2 with dedicated I/O level and function
Standby system for highly available automation solutions.
PCD3.M6880 standby controller
PCD3.T688 smart RIO for standby system
1.6
Standby System
