Overview of Saia PCD E-Line device series
1.6
PCD1 E-Line – compact design for electrical distributors
1.6.1
PCD1 E-Line system overview
Page
Description of the basic structure and system of the PCD1 E-Line series
1.6.2
PCD1 controller for E-Line
Page
The E-Controller for installation in electrical distributors is the ideal
controller as a master and Ethernet interface for the Saia PCD1 E-Line
PCD1.M2220-C15
additional Saia PCD® controllers
1.6.3
PCD1 E-Line full programmable modules
Page
Programmable modules for specific applications
PCD1.G1100-C15 Light and shade module
PCD1.G360x-C15 Room module
PCD1.F2611-C15 DALI module and add. RS-485
PCD1.W5300-C15 Analogue module
1.6.4
PCD1 E-Line input and output modules
page
I/O modules with override operating level
PCD1.Bxxxx-A20 Digital modules
PCD1.Gxxxx-A20 Combined modules
1.6.5
E-Line system components
page
Extension of the communication options
PCD7.T4850-RF RF modem, RS-485
Power supplies
PQA Power Quality Manager
78
80
83
90
92
