Technical data and ordering information
for PCD2.M4xxx controllers
Accessories, e.g. connectors, covers, etc. are described in the last page of this chapter.
Details can be found in the manual 27-645.
Ordering information
Type
Description
PCD2.M4160
PCD2 processor unit with Ethernet TCP/IP, 512 kbytes program memory, 64 I/Os
PCD2.M4560
PCD2 processor unit with Ethernet TCP/IP, 2 MB program memory, 1,023 I/Os
Technical overview
Technical data
PCD2.M4160
PCD1.M4560
Number of digital inputs onboard
4 digital inputs (24 V, 4× interrupt)
Number of digital inputs/outputs in the base unit
resp. I/O module slots in the base unit
64
4
Number of digital inputs/outputs expandable with PCD2.C2000 and
PCD2.C1000 module holders
resp. I/O module slots
960
60
Processing time [µs]
Bit operation
Word operation
0.1…0.8 μs
0.3 μs
Real-time clock (RTC)
Yes
Supercap to support real-time clock
< 10 days
Slot for optional battery holder module
Order number 4 639 4898 0
Yes, to support real-time clock for < 3 years
Onboard memory
Program memory, DB/text (flash)
512 kB
2 MB
User memory, DB/text (RAM)
128 kB
1 MB
Flash memory (S-RIO, configuration and backup)
128 MB
128 MB
User flash file system (INTFLASH)
8 MB
128 MB
Data backup with FRAM technology (the data is retained in a de-energised state)
for R, F, DB, TEXT
for R, F, DB, TEXT
Onboard interfaces
USB 1.1
≤ 12 Mbit/s
Ethernet, 2-port switch
≤ 10/100 Mbit/s, full duplex, auto-sensing/auto-crossing
RS-485 on terminal block (port 0)
≤ 115.2 kbit/s
RS-485 free protocols on D-Sub connector (port 2) or
RS-485 Profibus-DP Slave, Profi-S-Net on D-Sub connector (port 10)
No
≤ 115.2 kbit/s
≤ 1.5 Mbit/s (elec. isolated)
Additional interfaces
PCD2.F2xxx modules for RS-232, RS-422, RS-485,
BACnet MS/TP, Belimo MP-Bus, DALI and M-Bus
I/O slot 0…1
2 modules
I/O slot 0…3
4 modules
Slot A for PCD7.F1xxS modules
Yes
Slot C for Profibus module PCD7.F7500
No
Yes
General data
Supply voltage (in accordance with EN/IEC 61131-2)
24 VDC, –20/+25% max. incl. 5% ripple
Power consumption
typically 15 W for 64 I/Os
Load capacity 5 V/+ V internal
max. 800 mA/250 mA
