Communication & Interaction
2.6.9
Other drivers
Communication drivers fromwww.engiby.ch
Field bus, standard/universal interfaces
Modbus
(RTU/ASCII, TCP/IP, UDP/IP)
Schneider, Modicon and Telemecanique and many other devices via point-to-point connections –
modem – RS-232 – RS-422 – RS-485 Bus – TCP/IP – UDP/IP
M-Bus
Heating cost meter, water meter, impulse meter, electricity meter.
The driver supports F27xx modules as well as level converters for RS232/M-Bus, RS485/M-Bus
and TCP/IP to M-Bus gateways
3964(R) / RK512
Siemens: Point-to-point and multi-point connection
S-Bus for TCP/IP
S-Bus driver for multi-master applications, for efficient configuration in MS Excel tables
S-Bus for RS-xxx
S-Bus driver for quick response time with priority, for efficient configuration in MS Excel tables
ESPA 4.4.4
Send and receive Messages, forward and route Messages via SMS, pager or TAP
IEC 60870-5-101
Power plant/energy management
IEC 60870-5-103
Switching station controller
IEC 60870-5-104
Power plant/energy management
Text output
Configuration tool for transmitting formatted texts event triggered via serial interfaces, TCP/IP or UDP/IP.
Also supports SMS
Text parser
Configuration tool for reading and analyzing PCD text input
SNMP traps and PING
Transmission of SNMP Alarms/notification (NMS) and Syslog messages,
as well as efficiently in MS Excel tables configured PING of multiple IP hosts
EIB (KNX Configurator)
Configuration tool for the Saia EIB communication driver which allows the definition of the communication
to KNX devices in MS Excel tables. Additionally supports scenarios (transmission of multiple values to multi-
ple addresses with short interruptions between the transmissions)
Controller/energy
ExControl
Light and shade functions with remote access via RS-232 or Ethernet
TRSII
WITnet concept, remote control
COMSAB / York
SABROE compressor control device: – PROSAB II – UNISAB S / R / RT / RTH – UNISAB II
Luxmate
Lighting controller BMS ZUMTOBEL
Alarm/messages / access
DMS 7000
Siemens-Cerberus alarm systems (reduced driver)
Tyco MX
Tyco MX 1000 and 4000 alarm systems
Fidelio / FIAS
Hotel management system
TechTalk
Access control system
Video / Audio
Grundig VAZ
Video matrix
Commend
Interphone system
Others
Wilo / EMB
Pump controller
Grundfos pump control
Genibus via RS
-
485
ebmBUS
ebmPapst motor controller
Clock and GPS
Time signals received from DCF77 - Time and position received via GPS.
Time and meteo data received from Elsner station
Marksman
Road traffic counter
For German-speaking customers: Communication drivers from Kindler Gebäudeautomation GmbH,
Danfoss
KGA.Danfoss
FBox library for communicating with VLT 6000 / FC100 Danfoss® frequency inverters with the standard FC
communication protocol
Saia Burgess Controls communication drivers
P-Bus
Communication driver to Siemens P-Bus I/O level
N2-Bus
Communication driver to JCI-N2 bus for connecting JCI master or slave systems
