Communication & Interaction
4
Room automation
MP Bus |
Function modules (FBox)
All Belimo MP drives can exchange data with the PCD application program via a suitable FBox from the MP Bus FBox library. The master
communication FBox must be positioned once at the start of the application program. It controls the communication and fault recogni-
tion and creates ways of addressing the MP drives available for commissioning and service. Some MP drives also have an input for con-
necting sensors. R: Temperature sensor NI1000, PT1000…, U:voltage 0–32 V or 0–10 V and DI: Potential-free contact.
* only active sensors and switches can be connected
Type/performance categories
Sensors
MP Bus FBox
Communication drivers
MP Single
Ventilation applications
Damper drives with no safety function:
LM24A-MP (5 Nm), NM24A-MP (10 Nm), SM24A-MP (20 Nm), GM24A-MP (40 Nm)
Damper drives with safety function:
TF24-MFT (2 Nm), LF24-MFT2 (4 Nm), SF24A-MP (20 Nm)
Linear damper drives:
LH24A-MP100 / 200 / 300 (150 N), SH24A-MP100 / 200 / 300 (450 N)
Damper drives rotary:
LU24A-MP (3 Nm)
R, U, DI
MP Air
Safety applications
Drives for fire dampers:
BF24TL-T-ST (18 Nm), BFG24TL-T-ST (11 Nm)
Gateway for conventional fire damper drives:
BKN230-24-C-MP
Thermo-
element
MP BS
Room and system applications
VAV compact controller:
LMV-D3-MP (5 Nm), NMV-D3-MP (10 Nm), SMV-D3-MP (20 Nm)
VAV compact controller linear:
LHV-D3-MP (150 N)
VAV universal controller:
VRP-M
R, U, DI
MP VAV
…
Water applications
Lift drives with no emergency function:
LV24A-MP-TPC (500 N), LVC24A-MP-TPC (500 N), NV24A-MP-TPC (1000 N), NVC24A-MP-TPC (1000 N),
SV24A-MP-TPC (1500 N), SVC24A-MP-TPC (1500 N), EV24A-MP-TPC (2500 N)
Lift drives with emergency function:
NVK24A-MP-TPC (1000 N), NVKC24A-MP-TPC (1000 N),
AVK24A-MP-TPC (2000 N), adjustable closing point, adjustable emergency setting
R, U, DI
MP Linear
Drives for control ball valve with no emergency function:
LR24A-MP (5 Nm), NR24A-MP (10 Nm), SR24A-MP (20 Nm)
Drives for control ball valve with emergency function:
TRF24-MFT* (2 Nm), LRF24-MP (4 Nm), NRF24A-MP (10 Nm)
Drives for butterfly valves with no emergency function:
SR24A-MP-5 (20 Nm), GR24A-MP-5/-7 (40 Nm)
R, U, DI
MP Air
Drives for 6-way control ball valve:
LR24A-MP (5 Nm), NR24A-MP (10 Nm)
R, U, DI
MP 6 Way
Electronic pressure-independent control ball valve (EPIV):
P6…W…E-MP*
U, DI
MP EPIV
…
Belimo EnergyValve:
EV..R+BAC, P6..W..EV-BAC
U, DI
Energy Valve P6
Rotary actuator:
CQ24A-MPL (MP-Bus light)
—
MP MPL
Room sensors
Room combi-sensor, depending on design with temperature, CO
2
, VOC and relative humidity:
MS24A R…MPX
R, DL,
U (0–10 V)
MP THC24
MP THCV
Generic data transfer
For reading and transmitting data points not contained in the device-specific FBox. This FBox is used as a
functional extension for MP Bus FBoxes and can only be used with a device FBox specific to that device or a
generic device FBox.
MP Generic
MP PEEK
MP POKE
Third party devices
FBoxes are available for the following third party MP Bus devices:
PTH sensor from wmag AG, Switzerland,
UST-3, UST-5 from wmag AG, Switzerland.
Each MP Bus device can also be connected via generic devices and peek/poke FBoxes in PCD application
programs.
MP PTH
MP UST-3
MP Generic
MP PEEK
MP POKE
