Accessories
Order no.
Sealing cover for single-phase Saia PCD®
energy meter EMD1 and ALD1
2 units are recommended for contact protection.
(Also for termination boxes PCD7.T161 and
PCD7.T162, see Section 5.5)
4 104 7420 0
ALD1 with assembled sealing cover
Sealing cover for
– Single-phase Saia PCD® energy meter AAE1
– 3-phase Saia PCD® energy meter ALE3,
and AWD3
2 units are recommended for contact protection
on AAE1.
4 units are recommended for contact protection
on ALE3 and AWD3.
4 104 7485 0
ALE3 or AWD3 with sealing cover
Mounting frame for 3-ph energy meters
of the families ALE3/AWD3
PMK-EEM400
ALE3 or AWD3 mounted in panel kit
4.4.6
Energy meter – sealing cover
4.4.7
Application notes
Application notes on the subject of "energy" can be found on
the support page
) under the section
"energy meters".
