Automation stations – the basics
5
4
3
2
1
Cabinet
components
Dedicated
room controller
HMI Visualization
and operating
Automation
stations
Consumption data
acquisition
Programmable controller for measuring, regulation
and control tasks. Modular design consisting of
industrial quality CPU, I/O and communication modules
with life cycling lasting decades. The comprehensive
application software can be simply and reliably adapted
and extended throughout the life cycle.
It is applied on all automation station series
(Saia PCD1, 2, 3 and PCS1)
Automation stations
Presentation of the Saia PCD® Controls COSinus operating system – device platforms – program execution
– memory system and service capability.
Up to 1,023 I/Os – up to 13 simultaneously operated communication interfaces.
18 integrated I/Os which can be extended to max. 50 I/Os with 2 optional I/O modules –
up to 8 simultaneously operated communication interfaces.
Saia PCD3.T66x Ethernet Smart Remote I/O Station with 4 I/O slots
Saia PCD3.T760 as Profibus DP Remote I/O Station with 4 I/O slots
Saia PCD7.Lxx S-Bus RIO modules
External dimensions independent of the type and number of the integrated hardware modules.
Extensible system to max. 1,023 I/Os – up to 15 simultaneously operated communication interfaces.
Programmable compact controller for HeaVAC applications.
Tried and tested devices with 19, 30 and 44 I/Os for simple applications without Ethernet.
Cables and connectors for SBC system
External GSM, analog and ISDN modems for top-hat rail mounting
Saia PCD4.U100 upgrade kit for operating old PCD4 modules on new SBC controllers
1.2
Saia PCD3
Page
19
1.4
Saia PCD1
Page
53
1.6
Remote data points (RIOs)
Page
69
1.3
Saia PCD2
Page
41
1.5
Saia PCD® PCS1
Page
65
1.7
Accessories for controllers
Page
77
1.1
Basic properties of programmable Saia PCD® measuring, regulation and control devices
Page
8
Saia PCD3.Mxx6x as High Power CPU
Saia PCD3.M5xxx as standard control device
Saia PCD3.M3xxx as compact base unit
Saia PCD3.M2 with dedicated I/O level and function
