Communication & Interaction
Fully modular
Compact mo-
dular
pWeb
Panel
PCD3
RIO PCD2
PCD1
PCD7
I/O data points
PCD3.M3120/M3160
PCD3.M3330/M3360
PCD3.M5340/M5360
PCD3.M5540/M5560
PCD3.M6560
PCD3.M6860/M6880
PCD3.T665
PCD3.T666/T668
PCD2.M4160
PCD2.M4560
PCD2.M5540
PCD1.M2120/M2160
PCD1.M0160E0
PCD1.M2110R1
PCD1.M2220-C15
PCD7.D457VT5F
PCD7.D410VT5F
PCD7.D412DT5F
Onboard (data points)
– – – – – – – – 4 4 – 18 18 24 7 – – –
Onboard I/O slots
1)
4 4 4 4 4 4 4 4 4 4 8 2 – 1 2 – – –
Optional I/O slots using expansion modules
1)
– 60 60 60 60 60 3 3 – 60 56 – – – – – – –
Maximum number of I/Os
1)
64 10231023102310231023 256 256 64 10231023 50 18 40 50 – – –
Maximum number of interfaces
(incl. PGU, USB, Ethernet)
11 11 13 13 13 12 2 11 6 10 15 8 4 6 8 4 4 4
Onboard interfaces
RS-232, PGU up to 115 kBit/s (Port #0)
– –
● ● ●
– – –
● ● ●
– – – – – – –
USB 1.1 device, PGU
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Ethernet TCP/IP 10/100 MBit
Fullduplex, autosensing/crossing
1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1
RS-485 up to 115 kBit/s or
● ●
– –
● ●
–
●
– – –
● ● ● ● ● ● ●
Profi S-Net up to 187.5 kBit/s
● ● ●
–
● ●
– – – – –
● ● ● ●
– – –
RS-422/485 up to 115 kBit/s (Port #3) or
– –
●
– – – – – – – – – – – – – – –
RS-485 up to 115 kBit/s electrically isolated (Port #3) or
– – –
●
– – – –
● ● ●
– – – – – – –
Profi DP slave, Profi S-Net up to 1.5 MBit/s (Port #10)
– – –
●
– – – –
● ● ●
– – – – – – –
Profibus DP master up to 12 MBits/s
– – – –
●
– – – – – – – – – – – – –
Optional interfaces
Slot C, Profibus DP master 12 MBit/s
– – – – – – – – –
● ●
– – – – – – –
BACnet® IP (with PCDx.R56x modules)
2)
● ● ● ● ● ●
– –
● ● ● ● ● ● ● ● ● ●
BACnet® MS/TP
3)
(with PCDx.R56x and PCDx.F215x
modules)
● ● ● ● ● ●
– –
● ● ● ●
–
● ●
– – –
L
on
® over IP (with PCDx.R58x modules)
3)
● ● ● ● ● ●
– –
● ● ● ● ● ● ●
– – –
Modbus RTU serial or IP
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Slot for PCD7.F1xxS (A1/A2)
– – – – – – – – 1 1 2 1 1 1 – 1 1 1
I/O slot #0 for PCD3.F1xx
RS-232 (RTS/CTS, DTR/DSR, CD, RI)
5)
PCD3.F121
● ● ● ● ● ●
–
●
– – – – – – – – – –
RS-485/RS-422 elec. connected
5)
PCD3.F110
● ● ● ● ● ●
–
●
– – – – – – – – – –
RS-485/RS-422 elec. isolated
6)
PCD3.F150
● ● ● ● ● ●
–
●
– – – – – – – – – –
Belimo MP Bus
5)
PCD3.F180
● ● ● ● ● ●
–
●
– – – – – – – – – –
I/O slot #0… #3 for PCD3
PCD3.F210 RS-485/422
5)
+ opt. PCD7.F1xxS
4 4 4 4 4 4 – – – – – – – – – – – –
PCD3.F215 BACnet MS/TP...
5)
+ opt. PCD7.F1xxS
4 4 4 4 4 4 – – – – – – – – – – – –
PCD3.F221 RS-232 full
5)
+ opt. PCD7.F1xxS
4 4 4 4 4 4 – – – – – – – – – – – –
PCD3.F240 L
on
FTT10
6)
+ opt. PCD7.F1xxS
4)
– – 4 4 4 4 – – – – – – – – – – – –
PCD3.F261 DALI incl. Bus power supply
6)
4 4 4 4 4 4 – 4 – – – – – – – – – –
PCD3.F27x M-Bus Master
5)
4 4 4 4 4 4 – 4 – – – – – – – – – –
PCD3.F281 Belimo MP Bus
+ opt. PCD7.F1xxS
5)
4 4 4 4 4 4 – – – – – – – – – – – –
I/O slot #0… #3 for PCD2 and
slot #0… #1 for PCD1 and
PCD2.F2100 RS-485/422
5)
+ opt. PCD7.F1xxS
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F2150 BACnet MS/TP...
5)
+ opt. PCD7.F1xxS
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F2210 RS-232 full
5)
+ opt. PCD7.F1xxS
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F2400 L
on
FTT10
6)
+ opt. PCD7.F1xxS
4)
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F2610 DALI incl. Bus power supply
6)
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F27x0 M-Bus Master
5)
– – – – – – – – 4 4 4 2 – 1 2 – – –
PCD2.F2810 Belimo MP Bus
5)
+ opt. PCD7.F1xxS
– – – – – – – – 4 4 4 2 – 1 2 – – –
Slots for modem (A1/A2)
– – – – – – – – – – 2 – – – – – – –
Using an external modem via RS-232 interfaces
● ● ● ● ● ●
– –
● ● ● ● ● ● ● ● ● ●
