Analysis of trend data (PChart)
If the user wishes to display or export trends, however they have
been compiled, PChart is the tool to use. The trend data can be
displayed in a variety of colours and different scales.
MALM ESPA 4.4.4
With this module, alarms can be forwarded to telecommunica-
tions systems with an ESPA 4.4.4 interface (serial, type RS-232),
to be output to the display of a telephone within the local
telephone network.
pSMS
With a GSM-compatible modem (not included), SMS messages
can be received and their content assessed according to a
specification (e.g. to acknowledge alarms or modify values).
SNMP Manager
Driver to monitor network components that provide SNMP
services, such as routers or controllers. The values polled
(depending on parameters set) are integrated into the Visi.Plus
database, where they can be processed further (e.g. for history
data or alarms).
Add-on programs
MALMVoice
When an alarm occurs, a voice message (sound file in WAV format)
will play via phone. The person called can then use the same call
to acknowledge the alarm by entering a sequence of numbers
(requires a DTMF-enabled telephone).
ESPA 4.4.4 (RCV)
Messages transmitted by telecommunications systems with an
ESPA 4.4.4 interface (serial, type RS-232) can be implemented as
alarm messages by Visi.Plus and used for further processing and
logging.
pCalc
Calculations for energy analysis and system monitoring,
up to 1,000 formulas with 16 variables each.
Mobile Alarm (MALM)
Remote alarms via e-mail/SMS
When monitoring technical building installations it is necessary
to guarantee that, in the absence of service personnel, fault
messages are forwarded quickly and safely. Direct diagnosis of
the fault message is also possible via remote dial-in, thus
avoiding unnecessary journeys by service personnel. The alarm
is sent via SMS or e-mail.
System requirements
Visi.Plus requires the following minimum configuration:
Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008 R2, Windows Server 22012
Processor Core 2 Duo
1024 MB RAM (the higher the number of DMS data points,
the more memory is required)
Hard disk with at least 1 GB free memory
CD-ROM drive (poss. external data backup (CD writer))
