Features
`
`
LAN-to-LAN industrial router (1× LAN int., 1× LAN ext.)
`
`
Professional IP routing
`
`
Comprehensive security: Firewall, VPN, SNMP
`
`
Easy consistent concept of operation
`
`
Quick start for SBC Connectivity Service (VPN service
The industrial high-speed router EBW-E100 allows secure connections between local and remote
networks.
EBW-E100 decouples manufacturing cells with remote access from the surrounding company IT
for example. Also many subnetworks with identical local IP addresses can be distinguished and
addressed targeted.
The firewall and VPN via OpenVPN and IPsec provide data security..
Typical applications
`
`
Manufacturing cell decoupling
`
`
Secure remote maintenance in customer network
`
`
Access to a control network from PLC, HMI, data logger
`
`
Remote desktop
`
`
Video monitoring
`
`
Displays
Technical data EBW-E100*
5.3.2
Industrial LAN router for VPN connection
Physical features
Dimensions (L×W×H)
110×45×70 mm
Operating temperature
–30…+70°C
–30…+85°C under limited conditions (refer to
)
Humidity
0…95% (non-condensing)
Supply
Connections
10…48 V DC (±20%)
Input/output terminals
Approx. 2 W
Additional features
Update of firmware and configuration (local and remote), daily auto update
Messages
Hardware watchdog, system messages via e-mail, SNMP traps, SNMP V1/V2c/V3
LAN
Ports
2×RJ45
Operating mode
10/100 MBit/s for full and half duplex operation
Function
Automatic detection of patch cable / cross-over cable, Automatic speed adjustment; MDI/MDI-X
Router
Function
Connection management, DHCP server and client, full NAT (port forwarding, netmapping), DNS relay, dynDNS support,
PPPoE client for ADSL, SNMP, NTP client and server, buffered real-time clock
Security
OpenVPN (client and server), IPsec, PPTP, MAC firewall, linkloss detection, failed login detection, GRE
Redundancy
2 OpenVPN server targets
Order details
Q.NET-EBW-E100
Industrial LAN router for VPN connection
Q.NET-EBW-H100
Industrial 3G/HSPA router for VPN connection
Q.NET-CON
Annual license for the “SBC Connectivity Service” portal
PCD7.K840
GSM/UMTS (850/900/1800/1900/2100 MHz) antenna with magnetic foot and SMA connector
*
In preparation, see Chapter C1“Product status”
