107
saia-pcd.com
PCD
7D
PCD7.D457-OWS1
+
255 mm
75 mm
304 mm
73,5 mm
219 mm
266 mm
Operation and monitoring
5
Switch cabinet
components
4
Consumer
data acquisition
3
Dedicated
room controllers
2
Operation
and monitoring
1
Automation
stations
On-wall mounting kit 5.7
”
/ 7”
on-wall
PCD7.D457-OWS
Wall mounting kit 5.7” / 7”
OEM or proprietary design
The standard 5.7”microbrowser panel without a front panel offers the potential for individual creativity. Whether it’s for modern
rooms or rustic spaces with customer-specific fronts in aluminium, black or wood, this modern technology can be easily and seam-
lessly integrated in accordance with the room requirements.
Panel with aluminium front
PCD7.D457VTCZ33
Panel with black front
PCD7.D457VTCZ35
Panel with mirror-effect front PCD7.D457VTCZ36
Panel with neutral front
PCD7.D457VTCZ11
Width 266 mm
Height 219 mm
Depth 73.5 mm
Order details
Type
Description
3 230 9178-001
Fixation set (4 pieces)
3 230 9178-002
Fixation set (6 pieces)
2.6.2
Fixation sets for Web Panel MB
