Room automation
4
Room automation
Saia PCD® controllers
Saia PCD controllers have sufficient system resources to operate up to 13 communication
interfaces in the same device. Even the most demanding tasks, such as simultaneous commu-
nication via BACnet® and L
on
IP, can be managed reliably.
Any challenge can be met with a Saia PCD owing to its flexible operation and high level of
reliability.
PCD7.L6xx control units for the combinable room control system
Control units are available for the Saia PCD7.L6xx combinable room controller that can be con-
nected direct to the reader via the RC-Bus or the input terminals. A range of room controllers
with analogue, digital or wireless connections are available for this. This enables the operation
for temperature values, ventilation, light, shade and presence. This product family portfolio is
rounded off by a high-quality 3.2” touch screen room controller.
Room controllers from PEHA
Control units from the PEHA are an outstanding addition to the Saia PCD controllers. The
room control units using EnOcean or PEHA PHC connection (RS-485) combined with the fully
programmable PCD1 E-Line products for example, are ideally suited for room automation ap-
plications. A wide range of control units is available which are easy to operate.
PCD7.D443WTxR Room Panels
The programmable panels have an attractive design. Independent room applications with the
integrated logic controller enable the control of room functions without a head station. Delays
through long communication channels associated with this are eliminated. The temperature
of the room or zone can also be determined and transmitted to another controller. The graph-
ics can be customised and therefore adjusted for any requirement.
PCD7.D4xxWeb Panels MB and pWeb Panels MB
The Saia PCD7.D4xx Web Panel MB and pWeb Panel MB are equally suitable for room auto-
mation. This is particularly true when executing and displaying tasks of greater complexity.
The use of the S-Web technology combined with the micro browser panel systems is a great
advantage. The operation can be displayed transparently and clearly for every user. Each indi-
vidual control side has a flexible design and can be created with Saia PG5 using the standard
objects or existing function templates.
Control units
MENÜ
KLIMA
21°C
23°C
Raumtemperatur
Lüftung
Aus
Stufe 3
Ist
Soll
