SBC Software
Web Editor window: Draft document
Web Editor window: Properties of view
The Web Editor includes a transparent and adjustable workspace for efficient operation. The workspace essentially comprises the menu/
command bar, the View Editor (drawing area) and windows. With docking window technology, the user can position and show/hide the
windows as required.
The most important windows are explained here:
Web Editor window: Project folder
The project folder displays
the project and file structure.
This folder may contain
multiple Web Editor projects
with various data types. The
file types are shown clearly in
an orderly tree structure.
The document outline
window provides an
overview of the structure of
the current view.
With this window, an element
can be selected directly,
regardless of its group or
level.
Web Editor window: Symbols
Web Editor window: Layers
Symbols are incorporated
from the configured PG5
project path and updated
automatically.
The window has a search
function to find symbols
quickly.
This window provides an
overview of all layers in the
view that are currently open.
Layers can be created, moved
or deleted. All layers,
including the background
and foreground view, can be
hidden for additional clarity.
In the "Properties" window,
the properties and behaviour
of objects at runtime are
quickly and easily configured
with just a few clicks.
The window is divided into
four areas.
Web Editor window: Library
All available elements,
images and templates are
listed in the Library window.
Like the Symbols window, a
search can be carried out in
the Library window.
Double-click on an element
to add it to the open view.
