Consumption data collection
With the field devices of the S-Monitoring system, electri-
cal energy is measured and signals from water, gas and
heating meters are captured. The S-Monitoring application
processes and visualises data automatically in a clearly
arranged manner. Thus, the system generates a high
degree of transparency regarding resource consumption.
This functions from just a few measuring points up to
thousands of measuring points in distributed properties.
Collect, visualise and process
consumption data
S-Monitoring makes it easy to manage energy and consumption. Ready-to-use directly from the packaging and
it does not require any complicated configuration and programming. It can also be customised to meet your
specific requirements – it is a system, that grows with you.
4.1
System overview
Page
Collect, convert and transmit S0 pulses: With the PCD7.H104 pulse counter modules, non-bus-capable meters
can also be integrated into an S-Monitoring system.
4.2
Saia PCD® S0 pulse counter
Page
The Power Quality Analyzer (PQA) is a device for measuring and checking the quality of the electricity system,
manufactured as a DIN rail unit in industrial quality.
4.5
Saia PCD® Quality Analyzer
Page
Saia Burgess Controls, is a European market leader in bus-capable energy meters for sub metering of ectrical
energy data: for machines, plants and building components.
4.4
Energy meters ALD, ALE and AWD
Page
The E-Monitor combines data capture, visualisation and logging in one compact control panel. It is delivered
pre-programmed with the S-Monitoring application.
4.7
Saia PCD® E-Monitor
Page
The E-Controller with S-Monitoring function combines data capture, visualisation and logging of energy
consumption in one compact device. Users can use the inputs and outputs to intervene in processes
for regulation.
4.8
Saia PCD® E-Controller
Page
S-Monitoring is an integral part of the COSinus operating system and is integrated into all controls with the
extension xx60 and the pWeb panels. It enables consumption data to be acquired automatically without time-
consuming programming and saves it on the file system.
4.6
S-Monitoring application
Page
Wireless transmission of RS-485 interfaces. Use as a wireless transponder or repeater.
4.3
Saia PCD® Radio Modem
Page
